Siemens JL3B250 Molded Case Circuit Breaker
- 250A
- 3 Pole
- Bolt-On
Siemens
JL3B250
Molded Case Circuit Breaker
Brand
Siemens
SKU
JL3B250
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens JL3B250 - 250A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
300A 3 Pole Molded Case Circuit Breaker
300A 3 Pole Molded Case Circuit Breaker
350A 3 Pole Molded Case Circuit Breaker
Description
A drop-in replacement for older distribution systems, the Siemens JL3B250 is a 250-amp, 3-pole molded case circuit breaker. It utilizes thermal-magnetic trip technology to deliver long-time and instantaneous (LI) protection for commercial environments. Designed for bolt-on installation, this J-Frame breaker fits into Siemens P4 and P5 panelboards, motor control centers, and legacy ITE FC-1 panels. It is replaced by the JD63B250 model.Specifications
| Brand | Siemens |
|---|---|
| Part Number | JL3B250-R |
| Series | JL |
| Amperage | 250A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 25kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | JL |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P4, P5 Panelboards, Switchboards, Motor Control Centers, Legacy ITE FC-1 Panelboards |
| Wire Gauge | 3/0 AWG - 500 kcmil |
| Max Wire | 500 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Lug Kits |
|---|---|
| Accessories | Lugs Not Included |
| Standards | UL 489, CSA C22.2 No. 5, NEMA AB-1 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Interchangeable Trip Unit |
Product FAQs
5 answersWhich panelboards and enclosures accept the Siemens JL3B250?
The JL3B250 is a bolt-on J-frame breaker compatible with Siemens P4 and P5 panelboards, switchboards, and motor control centers. It is also backward compatible with legacy ITE FC-1 panelboards.
Is there a modern replacement for the legacy JL3B250?
Yes, the Siemens JD63B250 is the direct modern replacement for the legacy JL3B250 J-frame circuit breaker.
What wire gauge range does the JL3B250 support?
When fitted with standard lugs, the breaker terminals accommodate wire sizes from 3/0 AWG up to 500 kcmil.
Is the JL3B250 suitable for direct current (DC) applications?
Yes, in addition to its standard AC ratings, this breaker is rated for use in 250VDC systems with a 30kAIC interrupting capacity.
How is the trip unit configured on the JL3B250?
It utilizes a thermal magnetic trip unit featuring a fixed thermal element for long-time overload protection and an adjustable magnetic element for instantaneous short-circuit protection.
