Siemens QS2175 Miniature Circuit Breaker
- 175A
- 2 Pole
- Plug-On
Siemens
QS2175
Miniature Circuit Breaker
Brand
Siemens
SKU
QS2175
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens QS2175 - 175A 2 Pole Miniature Circuit Breaker
New
Quantity
Similar Items
200A 2 Pole Miniature Circuit Breaker
200A 2 Pole Miniature Circuit Breaker
150A 2 Pole Miniature Circuit Breaker
Description
Providing standard 10kAIC protection, this 175A two-pole breaker functions as a reliable tenant main for multi-family and commercial buildings. It mounts into Siemens Power Mod meter stacks and Uni-PAK enclosures, serving as an exact replacement for the older MPD2175. The exclusive side-wired design utilizes right-hand bend wiring and requires no additional filler plates, saving valuable time during panelboard assembly.Specifications
| Brand | Siemens |
|---|---|
| Part Number | QS2175 |
| Series | QS |
| Amperage | 175A |
| Poles | 2 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC |
| Frame Type | Q |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Power Mod Meter Stacks, Uni-PAK Metering |
| Wire Gauge | 3 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | 3 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment |
|---|---|
| Accessories | Lugs Included |
| Standards | UL 489, CSA C22.2 No. 5 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip, Main Breaker |
Product FAQs
5 answersWhat metering equipment is compatible with the Siemens QS2175?
This 175A main breaker is designed specifically for installation in Siemens Power Mod meter stacks and Uni-PAK metering enclosures.
What is the direct replacement for the obsolete Murray MPD2175?
The Siemens QS2175 serves as the exact, drop-in replacement for the discontinued Murray MPD2175 main breaker.
Does the QS2175 require filler plates during installation?
No. The QS frame utilizes an exclusive side-wired design with right-hand bend wiring, allowing it to fit cleanly into compatible meter stacks without the need for filler plates.
How does the side-wired design of the QS frame benefit panel builders?
The side-wired configuration eliminates the need for S-bends in the conductors. This simplifies cable routing and saves valuable time during meter stack assembly.
What are the higher AIC alternatives to the standard QS2175?
The QS2175 provides 10kAIC protection. For applications requiring higher fault current ratings, alternatives include the QSH2175 at 22kAIC, QS2175HH at 42kAIC, and HQS2175H at 100kAIC.
