Square D FAP3610018M Motor Circuit Protector
- 100A
- 3 Pole
- Bolt-On
Square D
FAP3610018M
Motor Circuit Protector
Brand
Square D
SKU
FAP3610018M
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D FAP3610018M - 100A 3 Pole Motor Circuit Protector
Re-Certified
Quantity
Similar Items
100A 3 Pole Motor Circuit Protector
100A 3 Pole Motor Circuit Protector
100A 3 Pole Motor Circuit Protector
Description
Rated for 100A, this Square D magnetic-only circuit breaker is optimized for industrial motor branch circuit protection. By utilizing an adjustable instantaneous trip range of 300-1100A, it allows engineers to customize fault response while relying on separate overload relays for thermal protection. This bolt-on F-Frame unit installs into compatible Square D motor control centers.Specifications
| Brand | Square D |
|---|---|
| Part Number | FAP3610018M |
| Series | FAP |
| Amperage | 100A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC |
| Phase | 3 |
| AIC Rating | 25kA @ 240VAC, 18kA @ 480VAC, 14kA @ 600VAC |
| Amperage Range | 300-1100A |
|---|
| Frame Type | FAP |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D Motor Control Centers, Combination Motor Starters |
| Wire Gauge | 14-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Magnetic Only |
|---|---|
| Trip Function Code | I |
| Trip Function | Instantaneous Only |
| Trip Adjustability | Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Lug Kit: AL100FA (Included) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Motor Circuit Protector, Visual Trip Indicator |
