Square D FH36020 Molded Case Circuit Breaker
- 20A
- 3 Pole
- I-Line
Square D
FH36020
Molded Case Circuit Breaker
Brand
Square D
SKU
FH36020
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D FH36020 - 20A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Square D FH36020 - 20A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | FH36020 |
| Series | FH |
| Amperage | 20A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC, 480VAC, 600Y/347VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480Y/277VAC, 25kA @ 480VAC, 18kA @ 600Y/347VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | FH |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards |
| Wire Gauge | 14-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Visual Trip Indicator, Non-Interchangeable Trip |
Quantity
Square D FH36020 - 20A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | FH36020-R |
| Series | FH |
| Amperage | 20A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC, 480VAC, 600Y/347VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480Y/277VAC, 25kA @ 480VAC, 18kA @ 600Y/347VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | FH |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards |
| Wire Gauge | 14-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Visual Trip Indicator, Non-Interchangeable Trip |
Similar Items
20A 2 Pole Molded Case Circuit Breaker
20A 1 Pole Molded Case Circuit Breaker
20A 3 Pole Molded Case Circuit Breaker
Description
Engineered for industrial power distribution, the FH36020 delivers 20A of thermal-magnetic protection. This 3-pole molded case circuit breaker is part of Square D's trusted legacy F-Frame family, offering long-time and instantaneous (LI) trip functions. It features an I-Line mounting style for quick integration into compatible Square D panelboards. For modern replacements, this unit is superseded by the BGA36020 or HGA36020 models.Specifications
| Brand | Square D |
|---|---|
| Part Number | FH36020 |
| Series | FH |
| Amperage | 20A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC, 480VAC, 600Y/347VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480Y/277VAC, 25kA @ 480VAC, 18kA @ 600Y/347VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | FH |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards |
| Wire Gauge | 14-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Visual Trip Indicator, Non-Interchangeable Trip |
Product FAQs
8 answersWhat is the difference between the Square D FA36020 and the FH36020?
Both are 20A, 3-pole F-frame I-Line circuit breakers, but they differ in their Ampere Interrupting Capacity (AIC). The FH36020 is the high-interrupting version, offering 65kA at 240VAC and 25kA at 480VAC. The FA36020 is standard-interrupting, with lower ratings of 25kA at 240VAC and 18kA at 480VAC. The FH36020 can be used as a direct upgrade for an FA36020.
Is the FH36020 still an active production model?
No. The Square D F-frame molded case circuit breaker line is a legacy series and has been obsolete for several years. The direct modern replacement is the PowerPacT H-frame (such as the HGA36020 or HJA36020), which drops directly into the exact same I-Line busbar space.
Can I install this circuit breaker in a standard QO or Homeline panel?
No. The FH36020 features specialized I-Line plug-on jaws and is exclusively designed for use in Square D I-Line commercial panelboards and switchboards. It is physically incompatible with QO, Homeline, NQ, or NF load centers.
Will the FH36020 work in a standalone enclosure or unit-mount setup?
No. This breaker is specifically manufactured for I-Line busbar mounting and lacks line-side lugs. For a unit-mount (lug-to-lug) application where you need to attach wires to both sides of the breaker, you must use the FHL36020 or its modern PowerPacT equivalent.
How is the FH36020 physically secured inside an I-Line panelboard?
The line-side plug-on jaws are pressed directly onto the panelboard bus stack. To finalize the installation, a mounting foot on the opposite end (load side) of the circuit breaker is bolted into the panel's internal mounting pan, providing a secure and rigid connection.
What is the recommended termination torque for the load-side lugs?
The factory-standard AL50FA mechanical load lugs typically require a tightening torque of 35 lb-in for 14 to 4 AWG stranded copper or aluminum conductors. Always check the factory label on the side of the breaker to ensure strict compliance with NEC 110.14(D) before energizing.
Are the overcurrent trip thresholds on this breaker adjustable?
No. The FH36020 features a standard fixed thermal-magnetic trip unit. It provides Long-Time (thermal) and Instantaneous (magnetic) protection, but neither of these trip curves can be field-adjusted by the installer.
Can the FH36020 be used in industrial DC power circuits?
Yes. Alongside its standard alternating current ratings, this breaker is UL listed for direct current applications up to 250VDC. It carries a 10kA interrupting rating at 250VDC.
SuperClub
Join free. Get 500 SuperPoints.
Earn points on eligible purchases and redeem them at checkout.
100 SuperPoints = $1 off.
Warranties
Add an extra year of protection
60-Day Warranty
Your purchase includes 60 days of SuperBreakers warranty coverage.
Add a 1-year warranty extension in your cart.
Get a Quote
Don’t see what you’re looking for?
We source obsolete and hard-to-find parts every day.
Shipping
Free Shipping Policy
Parcel shipments with item value over $99 qualify for free economy shipping within the continental US. Please call to confirm special handling instructions. We do not charge a handling fee or require a minimum amount on any order. SuperBreakers does not ship on customer accounts.
Same Day Shipping
We strive to ship out your items the same day the order is placed. In rare circumstances SuperBreakers may reserve up to 5 business days to consolidate orders for complete shipment.
Expedited Shipments
Orders being shipped via Next Day Air, 2 Day Shipping or 3 Day Shipping must be received by 3 PM EST to guarantee same-day shipments. Expedited orders only ship on normal business days. Shipments will NOT be sent out on Saturdays and Sundays.
International Shipping
All International orders require a $1,000 minimum order threshold. Due to the special nature of these shipments, we require that these be placed with a SuperBreakers representative. Additional shipping and instructions will apply. All International Orders are Non-Cancel and Non-Refundable.
