Square D HJA260152 Molded Case Circuit Breaker
- 15A
- 2 Pole
- I-Line
Square D
HJA260152
Molded Case Circuit Breaker
Brand
Square D
SKU
HJA260152
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D HJA260152 - 15A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Square D HJA260152 - 15A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | HJA260152 |
| Series | HJA |
| Amperage | 15A |
| Poles | 2 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC, 480VAC, 600Y/347VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480Y/277VAC, 65kA @ 480VAC, 25kA @ 600Y/347VAC, 25kA @ 600VAC, 20kA @ 250VDC |
| Frame Type | H |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Switchboards |
| Wire Gauge | 14-3/0 AWG (Al/Cu) |
| Max Wire | 3/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Rotary Handle |
|---|---|
| Accessories | Load Side Lugs Included, Phase Connection AC (Factory Configured) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Current Limiting, Visual Trip Indicator, Reverse Feed, 80% Rated |
Sold out
Quantity
Square D HJA260152 - 15A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | HJA260152 |
| Series | HJA |
| Amperage | 15A |
| Poles | 2 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC, 480VAC, 600Y/347VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480Y/277VAC, 65kA @ 480VAC, 25kA @ 600Y/347VAC, 25kA @ 600VAC, 20kA @ 250VDC |
| Frame Type | H |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Switchboards |
| Wire Gauge | 14-3/0 AWG (Al/Cu) |
| Max Wire | 3/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Rotary Handle |
|---|---|
| Accessories | Load Side Lugs Included, Phase Connection AC (Factory Configured) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Current Limiting, Visual Trip Indicator, Reverse Feed, 80% Rated |
Similar Items
20A 2 Pole Molded Case Circuit Breaker
20A 2 Pole Molded Case Circuit Breaker
30A 2 Pole Molded Case Circuit Breaker
Description
Designed to accommodate AC phase requirements, this 15A thermal-magnetic circuit breaker delivers exceptional current-limiting protection for commercial facilities. It integrates seamlessly into Square D I-Line switchboards and panelboards, serving as a drop-in upgrade for legacy FH26015 components. With a high interrupting capacity of 100kA at 240V and 65kA at 480V, this PowerPacT H-Frame unit ensures robust performance and safety in demanding industrial electrical environments.Specifications
| Brand | Square D |
|---|---|
| Part Number | HJA260152 |
| Series | HJA |
| Amperage | 15A |
| Poles | 2 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480Y/277VAC, 480VAC, 600Y/347VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480Y/277VAC, 65kA @ 480VAC, 25kA @ 600Y/347VAC, 25kA @ 600VAC, 20kA @ 250VDC |
| Frame Type | H |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Switchboards |
| Wire Gauge | 14-3/0 AWG (Al/Cu) |
| Max Wire | 3/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Rotary Handle |
|---|---|
| Accessories | Load Side Lugs Included, Phase Connection AC (Factory Configured) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Current Limiting, Visual Trip Indicator, Reverse Feed, 80% Rated |
Product FAQs
9 answersWhat type of panels is the HJA260152 compatible with?
It is designed for use in Square D I-Line panelboards and switchboards. It features an I-Line style plug-on connection for the line side and mechanical lugs on the load side.
How does the I-Line connection mount to the panelboard?
The breaker uses a plug-on I-Line connection on the line side that snaps directly onto the panelboard bus. The load side uses standard mechanical lugs for wire termination.
What wire sizes and materials does the load side lug accept?
The standard load side lug accepts 14 AWG to 3/0 AWG aluminum or copper conductors (Al/Cu).
What is the recommended tightening torque for the load side lugs?
For the standard lugs, the tightening torque is 44 lb-in (5 N.m) for 14 to 10 AWG wire, and 124 lb-in (14 N.m) for 8 to 3/0 AWG wire.
What does the "J" in the HJA260152 part number signify?
The "J" indicates the interrupting rating tier of the PowerPacT H-frame breaker. For this model, it provides a high interrupting capacity of 100kA at 240VAC, 65kA at 480VAC, and 25kA at 600VAC.
Is the trip unit on the HJA260152 adjustable?
This breaker features a thermal magnetic trip unit with fixed thermal protection for overloads and adjustable magnetic protection for instantaneous short-circuit faults.
Can the HJA260152 replace older Square D circuit breakers?
Yes, this PowerPacT H-frame breaker serves as a direct drop-in replacement for legacy Square D FH26015 I-Line circuit breakers.
Does this breaker provide visible trip indication?
Yes, PowerPacT H-frame breakers feature a three-position handle (ON, OFF, TRIPPED). The center tripped position provides clear visual confirmation when the breaker has opened due to a fault.
What internal mechanism does the HJA260152 use to limit fault currents?
PowerPacT H-frame circuit breakers feature dual-break rotating contacts that help reduce peak current during short-circuit fault conditions, providing enhanced current-limiting protection.
