Schneider Electric HJA36125 Circuit Breaker
- 125
- 3 Pole
- I-Line
Schneider Electric
HJA36125
Circuit Breaker
Brand
Schneider Electric
SKU
HJA36125
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Schneider Electric HJA36125 3 Pole Circuit Breaker
New
Quantity
Quantity
Schneider Electric HJA36125 3 Pole Circuit Breaker
New
Quantity
| Brand | Schneider Electric |
|---|---|
| Part Number | HJA36125 |
| Series | PowerPact H |
| Amperage | 125 A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 600VAC |
| Phase | 3 |
| AIC Rating | 65kAIC at 480VAC |
| Frame Type | H |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Switchboards |
| Wire Gauge | AWG 14 to AWG 3/0, Al/Cu |
| Max Wire | 3/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Standards | RoHS, REACh, HACR |
| Approval | UL, CSA, CE, NEMA, NOM, IEC |
| Temp Rating | -25C to 70C |
| Construction Features | Current Limiting, HACR Rated, Visual Trip Indicator, Reverse Feed, Non-Interchangeable Trip |
Quantity
Schneider Electric HJA36125 3 Pole Circuit Breaker
Re-Certified
Quantity
| Brand | Schneider Electric |
|---|---|
| Part Number | HJA36125-R |
| Series | PowerPact H |
| Amperage | 125 A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 600VAC |
| Phase | 3 |
| AIC Rating | 65kAIC at 480VAC |
| Frame Type | H |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Switchboards |
| Wire Gauge | AWG 14 to AWG 3/0, Al/Cu |
| Max Wire | 3/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Standards | RoHS, REACh, HACR |
| Approval | UL, CSA, CE, NEMA, NOM, IEC |
| Temp Rating | -25C to 70C |
| Construction Features | Current Limiting, HACR Rated, Visual Trip Indicator, Reverse Feed, Non-Interchangeable Trip |
Similar Items
110A 3 Pole Molded Case Circuit Breaker
150A 3 Pole Molded Case Circuit Breaker
150A 3 Pole Molded Case Circuit Breaker
Description
Schneider Electric HJA36125 3 Pole Circuit Breaker
The Schneider Electric HJA36125 is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 125 Amps and a voltage rating of 600VAC. It has an interrupting rating of 65kAIC at 480VAC. The HJA36125 has an I-Line style plug-in connection type and includes long time and instantaneous trip functions.
Specifications
| Brand | Schneider Electric |
|---|---|
| Part Number | HJA36125 |
| Series | PowerPact H |
| Amperage | 125 A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 600VAC |
| Phase | 3 |
| AIC Rating | 65kAIC at 480VAC |
| Frame Type | H |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Switchboards |
| Wire Gauge | AWG 14 to AWG 3/0, Al/Cu |
| Max Wire | 3/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Standards | RoHS, REACh, HACR |
| Approval | UL, CSA, CE, NEMA, NOM, IEC |
| Temp Rating | -25C to 70C |
| Construction Features | Current Limiting, HACR Rated, Visual Trip Indicator, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
6 answersWhat panels are compatible with the HJA36125 circuit breaker?
This breaker is engineered specifically for Square D I-Line panelboards and switchboards. The line side features plug-on jaws that seat directly onto the panel bus, while the load side utilizes standard mechanical lugs.
Can the PowerPact HJA36125 replace older F-frame I-Line breakers?
Yes. The PowerPact H-frame occupies the same I-Line mounting space as Square D's discontinued F-frame breakers. It serves as a direct plug-on replacement for older 125-amp FA, FH, and FC series circuit breakers.
What are the wire size and torque specifications for the load lugs?
The factory mechanical lugs accept aluminum or copper conductors from 14 AWG to 3/0 AWG. Terminal tightening torque is 44.3 lb-in for 14 to 10 AWG wire, and 123.9 lb-in for heavier 8 to 3/0 AWG conductors.
Are the trip settings adjustable on this breaker?
No. The HJA36125 is equipped with a traditional thermal-magnetic trip unit providing fixed long-time and instantaneous protection. The magnetic hold current is factory set at 900A and the magnetic trip is set at 1700A.
Can this circuit breaker be used in direct current systems?
Yes. Alongside its standard alternating current ratings, the HJA36125 is UL listed for direct current distribution applications up to 250VDC.
What does the I-Line plug-in connection type involve?
I-Line is a specialized bus system from Square D. Breakers with an I-Line connection do not require bolt-on line cables or straps. Instead, the breaker snaps directly onto the panel bus via built-in phase jaws, significantly speeding up panel assembly.
