Square D QO3501021 Miniature Circuit Breaker
- 50A
- 3 Pole
- Plug-On
Square D
QO3501021
Miniature Circuit Breaker
Brand
Square D
SKU
QO3501021
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D QO3501021 - 50A 3 Pole Miniature Circuit Breaker
New
Quantity
Similar Items
70A 3 Pole Miniature Circuit Breaker
80A 3 Pole Miniature Circuit Breaker
QO3201021 - 20A 3 Pole Miniature Circuit Breaker
Description
Providing advanced control for commercial systems, this 50A miniature circuit breaker includes a factory-installed 120/208/240VAC shunt trip. This allows the breaker to be tripped from a remote location using a separate voltage signal. The three-pole device requires four panel spaces and utilizes a plug-on connection to install into Square D QO load centers and NQ panelboards. Rated for 10kAIC at 240VAC, it features thermal-magnetic protection and the signature Visi-Trip indicator.Specifications
| Brand | Square D |
|---|---|
| Part Number | QO350-1021 |
| Series | QO |
| Amperage | 50A |
| Poles | 3 |
| Mounting Style | Plug-On |
| Voltage | 240VAC, 120/240VAC, 48VDC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC, 10kA @ 120/240VAC, 5kA @ 48VDC |
| Frame Type | QO |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | QO Load Centers, NQ Panelboards |
| Wire Gauge | 8-2 AWG (Cu/Al) |
| Max Wire | 2 AWG |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Padlock Attachment |
|---|---|
| Accessories | Shunt Trip |
| Standards | CSA C22.2 No. 5, HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Visual Trip Indicator, HACR Rated |
Product FAQs
5 answersWhat does the 1021 suffix in the QO3501021 part number indicate?
The -1021 suffix means this circuit breaker features a factory-installed 120/208/240VAC shunt trip. This allows the breaker to be tripped remotely via a separate control voltage signal.
How many panel spaces does the QO3501021 require?
This unit requires 4 full spaces in a Square D QO load center or NQ panelboard. The standard 3-pole breaker occupies three spaces, while the factory-installed shunt trip module requires one additional pole space.
Is there a bolt-on version of this breaker available?
Yes, if your NQ panelboard requires a bolt-on connection, the direct equivalent is the QOB3501021. It features the same 50A rating, 3-pole configuration, and factory-installed shunt trip, but utilizes bolt-on mounting.
How does the shunt trip module affect standard breaker protection?
The shunt trip does not interfere with the breaker's standard thermal-magnetic protection against overloads and short circuits. It simply provides an additional way to manually or automatically open the circuit from a remote location.
How is the shunt trip accessory wired?
The factory-installed shunt trip features its own dedicated terminals for control wiring. You must connect these to a separate 120VAC to 240VAC control power source. Applying the required control voltage will instantly open the breaker contacts.
