Square D QOB315EPD GFEP Miniature Circuit Breaker
- 15A
- 3 Pole
- Bolt-On
Square D
QOB315EPD
GFEP Miniature Circuit Breaker
Brand
Square D
SKU
QOB315EPD
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D QOB315EPD - 15A GFEP Miniature Circuit Breaker
New
Quantity
Similar Items
15A GFEP Miniature Circuit Breaker
15A GFEP Miniature Circuit Breaker
Description
Part of the QO family, this 15-amp, three-pole breaker delivers 30mA ground fault equipment protection for 240VAC commercial systems. It is specifically calibrated to protect heat tracing, snow melting, and industrial machinery from damaging ground faults without the nuisance tripping associated with 5mA personnel devices. The robust bolt-on configuration installs into Square D NQ and NQOD panelboards. It comes equipped with a pigtail neutral and the highly visible Visi-Trip indicator.Specifications
| Brand | Square D |
|---|---|
| Part Number | QOB315EPD |
| Series | QOB |
| Amperage | 15A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Terminal Type | Pressure Plate |
|---|---|
| For Use With | NQ Panelboards, NQOD Panelboards |
| Wire Gauge | 14-8 AWG (Cu), 12-8 AWG (Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | GFEP |
|---|---|
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Padlock Attachment |
| Accessories | Pigtail Neutral, Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489, NEMA AB 1 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Visual Trip Indicator, Equipment Protection Device (30mA) |
Product FAQs
5 answersWhich panelboards are compatible with the QOB315EPD?
This bolt-on circuit breaker is designed exclusively for use in Square D NQ and NQOD panelboards. It will not fit in standard QO load centers, which require plug-on breakers.
What does the EPD designation mean on this breaker?
EPD stands for Equipment Protection Device. It provides a 30mA ground fault trip threshold designed to protect machinery and equipment, such as heat trace systems, from damage while preventing nuisance tripping. It is not a Class A GFCI for personnel protection.
How many pole spaces does the QOB315EPD require in a panel?
This is a 3-pole breaker that occupies three standard 3/4-inch spaces in an NQ or NQOD panelboard, requiring a total width of 2.25 inches.
How is the neutral connected on this breaker?
The QOB315EPD features a pigtail neutral wire. This wire must be securely connected to the neutral bar in the panelboard for the ground fault equipment protection circuitry to function properly.
Can I use this breaker to replace a standard QOB315?
Yes, if your application requires adding 30mA equipment ground fault protection. It has the same physical footprint and bolt-on mounting as a standard 3-pole 15A QOB breaker, but requires a connection to the panel neutral.
