ABB / General Electric TLB234175 Molded Case Circuit Breaker
- 175A
- 3 Pole
- Bolt-On
ABB / General Electric
TLB234175
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
TLB234175
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric TLB234175 - 175A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
ABB / General ElectricTLB234150
150A 3 Pole Molded Case Circuit Breaker
ABB / General ElectricTLB134100
100A 3 Pole Molded Case Circuit Breaker
ABB / General ElectricTLB134040
40A 3 Pole Molded Case Circuit Breaker
Description
Designed to handle high-capacity loads, the TLB234175 is a 3-pole, 175A molded case circuit breaker. As part of the GE Tri-Break family, it provides dependable thermal magnetic protection for industrial applications. The bolt-on mounting ensures a secure fit within GE panelboards, switchboards, and motor control centers. For future-proofing, this breaker transitions to the newer Tmax XT4 platform. With an integrally fused architecture, it delivers a 50kAIC interrupt rating at 480VAC.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TLB234175-R |
| Series | TLB |
| Amperage | 175A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 50kA @ 480VAC |
| Frame Type | TLB2 |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Switchboards, Motor Control Centers, Panelboards |
| Wire Gauge | 4 AWG - 300 kcmil |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Lugs |
| Standards | UL 489, NEMA AB 1 |
| Approval | UL |
| Temp Rating | 40C |
| Construction Features | Integrally Fused, Current Limiting, HACR Rated, Non-Interchangeable Trip, Trip-Free Mechanism, Quick-Make/Quick-Break |
Product FAQs
7 answersWhat enclosures are compatible with the TLB234175 breaker?
This bolt-on breaker is designed for installation in General Electric switchboards, motor control centers, and panelboards that accommodate the Tri-Break TLB2 frame.
What is the interrupting capacity of the TLB234175 at different voltages?
It provides an interrupting rating of 65kA at 240VAC and 50kA at 480VAC, making it suitable for high-fault commercial and industrial applications.
What wire gauge range is supported by the terminals on this breaker?
The standard line and load lugs accept conductors ranging from 4 AWG up to 300 kcmil. Ensure proper torque specifications are followed during installation.
Will I receive an ABB or GE branded breaker when ordering the TLB234175?
Because ABB acquired GE Industrial Solutions, this exact breaker may ship with either ABB or General Electric branding. Both versions share the same specifications and are fully interchangeable.
How is the TLB234175 mounted inside an electrical panel?
It features a bolt-on mounting configuration with a feed-thru connection, meaning it must be bolted directly to the bus system rather than snapping into place.
Are the trip settings adjustable on the TLB234175?
No, this breaker uses a fixed thermal-magnetic trip unit. Both the long-time and instantaneous (LI) trip functions are factory set and cannot be adjusted in the field.
What does the Tri-Break designation mean for this circuit breaker?
The GE Tri-Break family utilizes an integrally fused design to provide current-limiting protection, which helps minimize thermal and magnetic stress on downstream equipment during a short circuit.
