General Electric TEYF120 1 Pole Circuit Breaker

New

$230.72 In stock

Quantity

Description

General Electric TEYF120 1 Pole Circuit Breaker

The General Electric TEYF120 is a 1 Pole thermal magnetic molded case circuit breaker with a current rating of 20 Amps and a voltage rating of 120/240/277/480VAC, 125VDC. It has an interrupting rating of 18kA at 277VAC. The TEYF120 has a bolt-on connection type and includes long time and instantaneous trip functions.

Specifications

Brand General Electric
Series TEY
Amperage 20
Voltage 120/240/277/480VAC, 125VDC
Poles 1
Phase 1
Interrupting Rating 18kA at 277VAC
Frame Type TEY
Connection Type Bolt-On
Protection Thermal Magnetic
Functions Long Time and Instantaneous Trip
Terminal Connection Lug
For Use With GE Light Panels, Motor Control Centers and Panelboards
Standards UL, CSA
Temperature Rating 40°C
Circuit Breaker Type Standard
Actuator Type Toggle
Body Material Plastic
Max Wire Size 10 AWG
Min Wire Size 14 AWG
Mpn TEYF120
Upc 783164388220
