Siemens QF130AN GFCI Miniature Circuit Breaker
- 30A
- 1 Pole
- Plug-On
Siemens
QF130AN
GFCI Miniature Circuit Breaker
Brand
Siemens
SKU
QF130AN
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens QF130AN - 30A GFCI Miniature Circuit Breaker
New
Quantity
Similar Items
30A GFCI Miniature Circuit Breaker
25A GFCI Miniature Circuit Breaker
20A GFCI Miniature Circuit Breaker
Description
Utilizing an advanced plug-on neutral design, this 30-amp ground fault interrupter eliminates the need for a traditional pigtail wire to significantly reduce gutter clutter. It installs seamlessly into contemporary Siemens SN and PN series load centers for fast, clean residential wiring. Delivering Class A 5mA protection with a 10kAIC rating, the breaker includes self-testing functionality and an Insta-Wire feature to help contractors meet NEC wet location codes efficiently.Specifications
| Brand | Siemens |
|---|---|
| Part Number | QF130AN |
| Series | QF |
| Amperage | 30A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC |
| Frame Type | Q |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Plug-On Neutral Load Centers (SN, PN Series) |
| Wire Gauge | 14-10 AWG (Cu), 12-8 AWG (Al) |
| Max Wire | 10 AWG (Cu), 8 AWG (Al) |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | GFCI |
|---|---|
| Available Options | Padlock Attachment |
| Accessories | LED Trip Indicator |
| Standards | CSA C22.2 No. 144, UL 489, UL 943 |
| Approval | CSA, UL |
| Temp Rating | 40C |
Product FAQs
7 answersWhat load centers are compatible with the Siemens QF130AN?
This breaker is designed exclusively for Siemens Plug-On Neutral load centers, specifically the SN and PN series. It will not fit older panels that require a pigtail neutral connection.
What is the difference between the Siemens QF130A and QF130AN?
The QF130AN features a Plug-On Neutral design that connects directly to the neutral bar in compatible panels, eliminating the pigtail wire. The QF130A is the traditional version that includes a pigtail wire for the neutral connection.
What level of ground fault protection does the QF130AN provide?
This breaker provides Class A ground fault protection. It is designed to trip when it detects a ground fault of 5mA, which is the standard required for personnel safety in wet locations.
Does this breaker require a pigtail wire to connect to the neutral bar?
No. The QF130AN utilizes a Plug-On Neutral connection, allowing it to clip directly onto the neutral bar of a compatible Siemens SN or PN series load center. This speeds up installation and reduces gutter clutter.
Is the QF130AN suitable for HVAC equipment?
Yes, this breaker is HACR rated, making it suitable for use with heating, air conditioning, and refrigeration equipment that requires a 30A, 120VAC circuit.
How can I tell if the QF130AN tripped due to a ground fault?
The QF130AN includes a built-in LED trip indicator. If the breaker trips specifically due to a ground fault, the LED will illuminate to help you quickly identify the cause of the fault versus a standard overload.
Does the QF130AN have a self-test feature?
Yes, this breaker includes an automatic self-test and lockout feature. It routinely tests its internal ground fault circuitry to ensure continuous protection, locking out if the GFCI protection is compromised.
