Eaton / Cutler-Hammer EB2060 Molded Case Circuit Breaker
- 60A
- 2 Pole
- Bolt-On
Eaton / Cutler-Hammer
EB2060
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
EB2060
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer EB2060 - 60A 2 Pole Molded Case Circuit Breaker
New
Quantity
Sold out
Quantity
Eaton / Cutler-Hammer EB2060 - 60A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | EB2060 |
| Series | EB |
| Amperage | 60A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 125/250VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC, 5kA @ 125/250VDC |
| Frame Type | EB |
|---|---|
| Terminal Type | Lugs |
| For Use With | Westinghouse FDP, CDP Panelboards |
| Wire Gauge | 14-1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Standard Interrupting Capacity |
Sold out
Quantity
Eaton / Cutler-Hammer EB2060 - 60A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Series | EB |
| Amperage | 60A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 125/250VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC, 5kA @ 125/250VDC |
| Frame Type | EB |
|---|---|
| Terminal Type | Lugs |
| For Use With | Westinghouse FDP, CDP Panelboards |
| Wire Gauge | 14-1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Standard Interrupting Capacity |
Similar Items
30A 2 Pole Molded Case Circuit Breaker
25A 2 Pole Molded Case Circuit Breaker
100A 2 Pole Molded Case Circuit Breaker
Description
Part of the legacy E-Frame series, the Eaton EB2060 is a 2-pole, 60A molded case circuit breaker. It delivers dependable thermal-magnetic protection for commercial electrical systems. Designed with a bolt-on mounting style, this unit installs into vintage Westinghouse FDP and CDP panelboards. It is an ideal maintenance component for existing setups, with the EHD2060 serving as its modern substitute. Operating at 10kAIC at 240VAC, it includes fixed trip settings and load side lugs.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | EB2060 |
| Series | EB |
| Amperage | 60A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 125/250VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC, 5kA @ 125/250VDC |
| Frame Type | EB |
|---|---|
| Terminal Type | Lugs |
| For Use With | Westinghouse FDP, CDP Panelboards |
| Wire Gauge | 14-1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Standard Interrupting Capacity |
Product FAQs
5 answersWhich vintage panelboards are compatible with the EB2060 circuit breaker?
The EB2060 is designed as a bolt-on replacement for older Westinghouse and Cutler-Hammer CDP and FDP series panelboards.
Is there a modern replacement for the legacy EB2060 breaker?
Yes, the Eaton EHD2060 serves as the modern F-Frame substitute for the legacy EB-Frame EB2060, offering the same 60A rating and 2-pole configuration.
Can the EB2060 be used in direct current (DC) applications?
Yes, this thermal magnetic breaker carries a DC rating of up to 250VDC with a 5kA interrupting capacity, making it suitable for specific battery or solar control panels.
What mounting hardware is required to install the EB2060 in a CDP or FDP panelboard?
Installing an EB-Frame breaker like the EB2060 into a Westinghouse CDP or FDP panelboard typically requires an FB1K twin branch mounting hardware kit.
Will this breaker replace older Westinghouse EB models?
Yes, Eaton acquired the Westinghouse distribution equipment line. The Cutler-Hammer or Eaton EB2060 is a direct, exact-fit replacement for the original Westinghouse EB2060.
