Eaton / Westinghouse FA3025 Molded Case Circuit Breaker
- 25A
- 3 Pole
- Bolt-On
Eaton / Westinghouse
FA3025
Molded Case Circuit Breaker
Brand
Eaton / Westinghouse
SKU
FA3025
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Westinghouse FA3025 - 25A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
100A 3 Pole Molded Case Circuit Breaker
25A 3 Pole Molded Case Circuit Breaker
25A 3 Pole Molded Case Circuit Breaker
Description
Built for commercial and industrial applications, the 25A FA-frame breaker delivers robust thermal-magnetic protection. It serves as an exact fit for aging infrastructure requiring F-frame components. This unit mounts into classic Westinghouse panelboards, motor control centers, and modern Eaton Pow-R-Line C enclosures. It is frequently replaced by the newer FD3025 model in updated systems. Rated at 18kAIC at 240VAC, it features AB De-Ion arc quenching to rapidly extinguish faults.Specifications
| Brand | Eaton / Westinghouse |
|---|---|
| Part Number | FA3025-R |
| Series | FA |
| Amperage | 25A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 18kA @ 240VAC, 14kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Westinghouse Panelboards, Motor Control Centers, Switchboards, Eaton Pow-R-Line C Panelboards |
| Wire Gauge | 14-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed |
Product FAQs
6 answersWhat is the modern replacement for the FA3025 circuit breaker?
In updated systems, the FA3025 is frequently replaced by the newer Eaton FD3025 model, which fits the same F-frame footprint and panelboard requirements.
Can the FA3025 be installed in modern Eaton panelboards?
Yes, while originally designed for classic Westinghouse panels, switchboards, and motor control centers, this F-frame breaker is also fully compatible with modern Eaton Pow-R-Line C panelboards.
What type of wire connections does the FA3025 support?
The breaker comes standard with load side mechanical lugs that accept 14 AWG to 1/0 AWG copper or aluminum conductors. The line side features a bolt-on connection for direct bus mounting.
Are the trip settings adjustable on the FA3025?
No, this breaker features a fixed thermal-magnetic trip unit. Both the long-time thermal and instantaneous magnetic trip functions are factory set and cannot be adjusted in the field.
Is the FA3025 rated for direct current applications?
Yes, alongside its standard AC voltage ratings, this breaker carries a DC rating of 10kA at 250VDC, allowing it to be used in compatible direct current control and distribution circuits.
What arc quenching technology does the FA3025 use?
This breaker utilizes AB De-Ion arc quenching technology to rapidly extinguish faults and protect the circuit during an overcurrent or short circuit event.
