Eaton / Westinghouse F3025 Molded Case Circuit Breaker
- 25A
- 3 Pole
- Bolt-On
Eaton / Westinghouse
F3025
Molded Case Circuit Breaker
Brand
Eaton / Westinghouse
SKU
F3025
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Westinghouse F3025 - 25A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
15A 3 Pole Molded Case Circuit Breaker
5A 3 Pole Molded Case Circuit Breaker
70A 3 Pole Molded Case Circuit Breaker
Description
Designed to support existing commercial infrastructure, this 25A thermal-magnetic breaker delivers dependable overcurrent protection. It ensures continuous operation for older electrical distribution equipment. Installs into Eaton Pow-R-Line C panelboards and classic Westinghouse enclosures. Facility managers can utilize this component to substitute failing FDB3025 or FD3025 breakers.Specifications
| Brand | Eaton / Westinghouse |
|---|---|
| Part Number | F3025-R |
| Series | F |
| Amperage | 25A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 18kA @ 240VAC, 14kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Westinghouse Panelboards, Eaton Pow-R-Line C Panelboards, Motor Control Centers |
| Wire Gauge | 14-1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Non-Interchangeable Trip |
Product FAQs
7 answersCan the F3025 replace other Westinghouse 25A F-frame breakers?
Yes, facility managers and electricians can utilize the F3025 to substitute failing FDB3025 or FD3025 circuit breakers in existing distribution equipment.
What enclosures and panelboards accept the F3025 breaker?
This bolt-on breaker installs directly into classic Westinghouse panelboards, Eaton Pow-R-Line C panelboards, and compatible motor control centers.
What wire gauge is supported by the load side terminals?
The load side lugs accept wire sizes ranging from 14 AWG up to 1/0 AWG. Ensure proper torque specifications are followed during installation.
Can this breaker be applied in DC circuits?
Yes, the F3025 carries a 250VDC rating with a 10kA interrupting capacity, making it suitable for specific direct current applications alongside its standard AC ratings.
How does the F3025 mount into the panelboard?
It utilizes a bolt-on mounting configuration, requiring it to be physically bolted to the panelboard busbar rather than snapping into place.
What type of overcurrent protection does the F3025 provide?
It uses a thermal-magnetic trip unit with fixed long-time and instantaneous (LI) functions, providing reliable protection against both sustained overloads and sudden short circuits.
Does the F3025 feature adjustable trip settings?
No, this breaker features fixed thermal and fixed magnetic trip settings. If adjustable trip curves are required for selective coordination, a different breaker family must be selected.
