Federal Pacific NAGF15 GFCI Miniature Circuit Breaker
- 15A
- 1 Pole
- Plug-On
Federal Pacific
NAGF15
GFCI Miniature Circuit Breaker
Brand
Federal Pacific
SKU
NAGF15
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Federal Pacific NAGF15 - 15A GFCI Miniature Circuit Breaker
New
Quantity
Quantity
Federal Pacific NAGF15 - 15A GFCI Miniature Circuit Breaker
New
Quantity
| Brand | Federal Pacific |
|---|---|
| Part Number | NAGF15-R |
| Series | NAGF |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC |
| Terminal Type | Box Lugs |
|---|---|
| For Use With | Federal Pacific Stab-Lok Load Centers |
| Wire Gauge | 14-2 AWG |
| Max Wire | 2 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | GFCI |
|---|---|
| Accessories | Pigtail Neutral |
| Standards | CSA C22.2 No. 144, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
Quantity
Federal Pacific NAGF15 - 15A GFCI Miniature Circuit Breaker
Re-Certified
Quantity
| Brand | Federal Pacific |
|---|---|
| Part Number | NAGF15-R |
| Series | NAGF |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC |
| Terminal Type | Box Lugs |
|---|---|
| For Use With | Federal Pacific Stab-Lok Load Centers |
| Wire Gauge | 14-2 AWG |
| Max Wire | 2 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | GFCI |
|---|---|
| Accessories | Pigtail Neutral |
| Standards | CSA C22.2 No. 144, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
Similar Items
25A GFCI Miniature Circuit Breaker
30A GFCI Miniature Circuit Breaker
Description
Designed for residential wet locations, this 15A ground fault circuit interrupter provides essential 5mA Class A personnel protection. It features a pigtail neutral connection to ensure accurate monitoring of current imbalances. This unit mounts into classic Federal Pacific Stab-Lok load centers, serving as an exact fit for older enclosures. It operates as a reliable substitute for the UBIF015N. Rated at 10kAIC for 120VAC systems, the thermal-magnetic trip mechanism responds quickly.Specifications
| Brand | Federal Pacific |
|---|---|
| Part Number | NAGF15-R |
| Series | NAGF |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC |
| Terminal Type | Box Lugs |
|---|---|
| For Use With | Federal Pacific Stab-Lok Load Centers |
| Wire Gauge | 14-2 AWG |
| Max Wire | 2 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | GFCI |
|---|---|
| Accessories | Pigtail Neutral |
| Standards | CSA C22.2 No. 144, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
Product FAQs
7 answersWhat panels are compatible with the NAGF15 circuit breaker?
This breaker is designed exclusively for use in Federal Pacific (FPE) Stab-Lok load centers. It utilizes the unique Stab-Lok connection style and will not fit panels from other manufacturers.
How does the NAGF15 connect to the neutral bar?
It features a pigtail neutral wire that must be connected directly to the panel's neutral bus bar. This connection is required to ensure accurate monitoring of current imbalances and proper ground fault operation.
What level of ground fault protection does the NAGF15 provide?
It provides 5mA Class A personnel protection. This makes it suitable for residential wet locations like bathrooms, kitchens, and garages where GFCI protection is required by electrical code.
Is the NAGF15 known by any other part numbers?
Yes, this 15-amp Stab-Lok GFCI breaker is frequently cross-referenced as catalog number NA115GF.
How does this breaker mount into the load center?
The NAGF15 utilizes the classic Stab-Lok plug-on mounting design, allowing it to snap securely into place on the bus bar of compatible FPE enclosures.
What wire sizes are accepted by the box lugs on the NAGF15?
The box lug terminals on this breaker accommodate copper or aluminum wiring ranging from 14 AWG to 2 AWG.
What type of trip mechanism does the NAGF15 use?
It uses a fixed thermal-magnetic trip mechanism for standard overload and short-circuit protection, combined with integrated ground fault interruption (LIG trip function).
