ABB / General Electric TEYF130 Miniature Circuit Breaker
- 30A
- 1 Pole
- Bolt-On
ABB / General Electric
TEYF130
Miniature Circuit Breaker
Brand
ABB / General Electric
SKU
TEYF130
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric TEYF130 - 30A 1 Pole Miniature Circuit Breaker
New
Quantity
Similar Items
30A 2 Pole Miniature Circuit Breaker
30A 3 Pole Miniature Circuit Breaker
ABB / General ElectricTHQL1130
30A 1 Pole Miniature Circuit Breaker
Description
The GE TEYF130 is a 30-amp, single-pole circuit breaker designed for demanding commercial and industrial lighting applications. It utilizes a proven thermal-magnetic trip unit to deliver precise long-time and instantaneous protection against overloads. Designed for bolt-on installation, this device fits perfectly into GE A-Series and AE lighting panelboards.Specifications
| Brand | ABB / General Electric |
|---|---|
| Series | TEYF |
| Amperage | 30A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 277VAC, 125VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 120VAC, 18kA @ 277VAC, 10kA @ 125VDC |
| Frame Type | TEY |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE A-Series Lighting Panels, GE AE Lighting Panels |
| Wire Gauge | 10-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Handle Lock, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5.1, UL 489 |
| Approval | CSA, HACR, HID, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, HID Rated, Quick-Make/Quick-Break, Non-Interchangeable Trip |
Product FAQs
7 answersWhat panelboards are compatible with the TEYF130 circuit breaker?
The TEYF130 is designed for use in GE A-Series and AE lighting panels. It features a bolt-on mounting base suitable for these grounded 480Y/277VAC systems.
What is the recommended lug torque for the TEYF130?
The lug tightening torque for the TEYF130 depends on the wire gauge. Apply 35 in-lb for 10 AWG, 40 in-lb for 8 AWG, and 45 in-lb for 6 to 4 AWG copper or aluminum wire.
Is the TEYF130 rated for HACR and HID applications?
Yes, this 30-amp breaker is UL listed for both HACR (Heating, Air Conditioning, and Refrigeration) and HID (High Intensity Discharge) applications.
How does the TEYF130 differ from the standard TEY130?
The primary difference is the short circuit interrupting capacity. The TEYF130 offers an 18kAIC rating at 277VAC, whereas the standard TEY130 is rated for 14kAIC at 277VAC. Both share the same physical dimensions and panel compatibility.
What is the difference between the TEYF, TEYD, TEYH, and TEYL series?
These series represent different short circuit interrupting tiers for GE A-Series panels at 277VAC. The TEYF is rated at 18kAIC, TEYD at 25kAIC, TEYH at 35kAIC, and TEYL at 65kAIC.
Can the TEYF130 be used in DC voltage applications?
Yes, the TEYF130 is rated for use in DC applications up to 125VDC, providing an interrupting capacity of 10kAIC.
Does the TEYF130 mount on a standard DIN rail?
No, the TEYF130 is a bolt-on molded case circuit breaker designed specifically for GE lighting panels. It is not compatible with DIN rail mounting systems.
