ABB / General ElectricTHQL1115GF
ABB / General Electric THQL1115PGFT GFCI Miniature Circuit Breaker
- 15A
- 1 Pole
- Plug-On
ABB / General Electric
THQL1115PGFT
GFCI Miniature Circuit Breaker
Brand
ABB / General Electric
SKU
THQL1115PGFT
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric THQL1115PGFT - 15A GFCI Miniature Circuit Breaker
New
Quantity
Similar Items
ABB / General ElectricTHQL1120GF
20A GFCI Miniature Circuit Breaker
ABB / General ElectricTHQL1120GFT
20A GFCI Miniature Circuit Breaker
ABB / General ElectricTHQL2115GFT
15A GFCI Miniature Circuit Breaker
Description
Engineered to streamline installation, this 15-amp self-testing GFCI eliminates the pigtail wire for a cleaner, faster setup. The plug-on neutral design connects straight to the panel's neutral bar during insertion. It fits perfectly into GE PowerMark Gold (PON versions) and ABB PowerMark PRO load centers. Regular automatic self-tests ensure the Class A 5mA ground fault protection remains active and compliant with the latest National Electrical Code requirements for damp locations.Specifications
| Brand | ABB / General Electric |
|---|---|
| Series | THQL |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | THQL |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | GE PowerMark Gold Load Centers (Plug-on Neutral), ABB PowerMark PRO Load Centers, ABB ReliaHome Load Centers (Plug-on Neutral) |
| Wire Gauge | 14-8 AWG (Cu), 12-8 AWG (Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | GFCI |
|---|---|
| Available Options | Padlock Attachment |
| Accessories | Self-Test Feature (Integrated) |
| Standards | UL 489, UL 943, CSA C22.2 No. 5, HACR |
| Approval | CSA, UL |
| Temp Rating | 60C to 75C |
Product FAQs
6 answersWhat load centers are compatible with the THQL1115PGFT?
This breaker is designed for use in GE PowerMark Gold, ABB PowerMark PRO, and ABB ReliaHome load centers that are equipped with a plug-on neutral bar.
Can I install the THQL1115PGFT in an older panel without a plug-on neutral bar?
No. The THQL1115PGFT requires a compatible plug-on neutral load center. For older panels that require a pigtail neutral connection, you must use the THQL1115GFT instead.
What is the difference between the THQL1115PGFT and the THQL1115GFT?
The THQL1115PGFT features a plug-on neutral connection that clips directly to the panel neutral bar. The THQL1115GFT uses a traditional pigtail wire that must be manually routed and terminated.
What level of ground fault protection does the THQL1115PGFT provide?
It provides Class A personnel protection, which is designed to trip when it detects a ground fault current of 5mA or greater. It also includes standard thermal-magnetic protection against overloads and short circuits.
Does the THQL1115PGFT include a self-test feature?
Yes, it includes automatic self-testing functionality to ensure the ground fault circuitry is operating correctly, along with a push-to-test button and an LED trip indicator.
How does the plug-on neutral design benefit the installation?
The plug-on neutral design eliminates the need to route and terminate a separate pigtail wire. This saves installation time and frees up gutter space inside the load center for a cleaner layout.
