ABB / General Electric TMQD22225 Molded Case Circuit Breaker
- 225A
- 2 Pole
- Bolt-On
ABB / General Electric
TMQD22225
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
TMQD22225
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric TMQD22225 - 225A 2 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
ABB / General ElectricTMQD22150
150A 2 Pole Molded Case Circuit Breaker
ABB / General ElectricTMQD22125
125A 2 Pole Molded Case Circuit Breaker
ABB / General ElectricTMQD22100
100A 2 Pole Molded Case Circuit Breaker
Description
A heavy-duty solution for power distribution, this 225A molded case circuit breaker offers reliable thermal-magnetic protection. It is well-suited for commercial environments requiring reverse feed capabilities. This bolt-on unit is designed for GE Meter Mod III meter stacks and A-Series panelboards. It serves as a direct fit for legacy systems and is replaced by the TMQV22225. With a 100kAIC rating at 120/240VAC, the breaker features common trip functionality and is HACR certified for HVAC.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TMQD22225 |
| Series | TMQD |
| Amperage | 225A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 100kA @ 120/240VAC |
| Frame Type | TMQD |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Meter Mod III Meter Stacks, GE A-Series Panelboards |
| Wire Gauge | 1 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | 1 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | HACR, UL 489 |
| Approval | UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Non-Interchangeable Trip, Common Trip, Reverse Feed |
Product FAQs
6 answersWhich GE panelboards and meter stacks accept the TMQD22225 breaker?
This 2-pole bolt-on breaker is designed for installation in GE A-Series panelboards and GE Meter Mod III meter stacks, where it is commonly utilized as a tenant main breaker.
What is the difference between the TMQD22225 and the TQD22225 or THQD22225?
The primary difference is the short-circuit interrupting rating. The TMQD22225 is rated for 100kAIC at 240V, whereas the TQD22225 is rated for 10kAIC and the THQD22225 is rated for 22kAIC. All three share the same physical frame size and bolt-on mounting configuration.
Can I use a TQD22225 in place of a TMQD22225?
You can only substitute a TQD22225 if the system fault current requires 10kAIC or less. The TMQD22225 provides a much higher 100kAIC rating. Always verify the required interrupting capacity of your panel before downgrading the AIC rating to ensure safe operation.
What are the acceptable wire sizes for the TMQD22225 lugs?
The factory-installed lugs accommodate copper or aluminum conductors ranging from 1 AWG up to 300 kcmil. Ensure you use the correct wire gauge based on the 225A circuit requirement and local electrical codes.
Are the thermal-magnetic trip settings on the TMQD22225 adjustable?
No, this breaker features fixed long-time and instantaneous (LI) trip functions. It does not have adjustable dials for customizing the trip curve.
Is the TMQD22225 the same physical size as standard GE THQL breakers?
No, the TMQD22225 is built on a larger molded case frame designed for commercial panels and meter stacks. It will not fit into standard residential load centers that take 1-inch THQL plug-in breakers.
