ABB / General Electric THQP145 Miniature Circuit Breaker
- 45A
- 1 Pole
- Plug-On
ABB / General Electric
THQP145
Miniature Circuit Breaker
Brand
ABB / General Electric
SKU
THQP145
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric THQP145 - 45A 1 Pole Miniature Circuit Breaker
New
Quantity
Similar Items
40A 1 Pole Miniature Circuit Breaker
35A 1 Pole Miniature Circuit Breaker
30A 1 Pole Miniature Circuit Breaker
Description
Engineered for residential power distribution, the GE THQP145 delivers 45A of thermal-magnetic protection. The compact half-inch width allows contractors to add new circuits to crowded panels without requiring a costly subpanel upgrade. This miniature plug-on breaker is designed specifically to mount into GE PowerMark Gold and PowerMark Plus load centers. Providing a 10kAIC rating at 120/240VAC, the HACR-rated device includes a quick-make/quick-break mechanism and box lug terminals.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | THQP145 |
| Series | THQP |
| Amperage | 45A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | THQP |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | GE PowerMark Gold Load Centers, GE PowerMark Plus Load Centers |
| Wire Gauge | 8-4 AWG (Cu), 8-4 AWG (Al) |
| Max Wire | 4 AWG |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment |
|---|---|
| Standards | CSA C22.2 No. 5, HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Quick-Make/Quick-Break, Half-Size (1/2 inch width per pole) |
Product FAQs
5 answersCan I install the THQP145 in any GE PowerMark load center?
While it is compatible with GE PowerMark Gold and PowerMark Plus load centers, the panel must specifically support half-inch THQP breakers. Not all slots in these panels have the required cross-shaped bus tabs to accept them.
What is the physical width of the THQP145 breaker?
As part of the THQP frame family, this is a half-inch wide miniature circuit breaker. It is designed to save space by allowing two single-pole breakers to occupy a single one-inch panel slot.
How does the plug-in connection of a THQP breaker differ from a standard THQL?
THQP breakers mount horizontally across the bus stabs rather than vertically. Your panel must have the specialized rejection clips and cross-shaped tabs to accept this half-inch design.
Is the THQP145 considered a tandem breaker?
The THQP145 is a standalone half-inch breaker, not a single-body tandem breaker. However, installing two THQP breakers side by side in a compatible panel achieves the same space-saving result as a tandem breaker.
Can I force this half-inch breaker into a standard one-inch slot if it does not fit?
No. If the breaker does not easily snap onto the bus, the slot is likely designed only for full-size one-inch breakers. Modifying the breaker or the panel bus to force a fit is a severe safety hazard and violates electrical codes.
