Siemens JK3B175 - 175A 3 Pole Molded Case Circuit Breaker

Brand Siemens
SKU JK3B175
Siemens JK3B175 3 Pole Circuit Breaker
Free Shipping Over $99

Siemens JK3B175 - 175A 3 Pole Molded Case Circuit Breaker

Brand Siemens
SKU JK3B175
Select Item Condition
Earn 1253 SuperPoints

Quantity
Planning a Big Order?
Bulk pricing available—let us know your needs for a quote.
Get a quote
Shop with Confidence
Enjoy a free 60-day warranty, extendable to 1 year at checkout.
Learn more
Siemens JK3B175 3 Pole Circuit Breaker

Siemens JK3B175 - 175A 3 Pole Molded Case Circuit Breaker

Re-Certified

$1253.96 In stock

Quantity

DescriptionSpecificationsSuperClubWarranties
Description
Built to support legacy infrastructure, this 175-amp molded case circuit breaker delivers essential thermal-magnetic protection for three-phase circuits. The bolt-on design fits seamlessly into Siemens SB1, SB2, and S5 switchboards, as well as P4 and P5 panelboards. With an interrupting capacity of 25kA at 240VAC and 14kA at 600VAC, it handles standard commercial fault levels. Facilities looking to upgrade can transition to the newer FXD63B175 substitute using an updated mounting strap kit.

Specifications

Brand Siemens
Series JK
Part Number JK3B175-R
Amperage 175A
Voltage 240VAC, 480VAC, 600VAC, 250VDC
Poles 3
Phase 3
AIC Rating 25kA @ 240VAC, 22kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC
Mounting Style Bolt-On
Terminal Type Lugs
For Use With Siemens P4, P5, SB1, SB2, S5 Panelboards, Switchboards
Trip Technology Thermal Magnetic
Trip Function Code LI
Trip Function Long-Time, Instantaneous
Trip Adjustability Fixed Thermal, Adjustable Magnetic
Wire Gauge 4 AWG - 350 kcmil (Cu/Al)
Max Wire 350 kcmil
Min Wire 4 AWG
Available Options Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch
Accessories Line and Load Lugs Included
Standards UL 489, CSA C22.2 No. 5
Approval CSA, UL
Temp Rating 40C
Construction Features HACR Rated, Reverse Feed, Non-Interchangeable Trip
