Square D QBL32225YP Molded Case Circuit Breaker
- 225A
- 3 Pole
- Unit Mount
Square D
QBL32225YP
Molded Case Circuit Breaker
Brand
Square D
SKU
QBL32225YP
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D QBL32225YP - 225A 3 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
250A 3 Pole Molded Case Circuit Breaker
200A 3 Pole Molded Case Circuit Breaker
200A 3 Pole Molded Case Circuit Breaker
Description
Built for commercial and industrial applications, the Square D QBL32225YP is a 3-pole, 225A molded case circuit breaker from the PowerPacT Q-Frame family. This unit-mount breaker installs into individual enclosures, switchboards, and panelboards. It serves as an exact replacement for legacy Q23225 breakers, ensuring seamless facility upgrades. Rated for 10kAIC at 240VAC, it features a factory-installed padlock attachment (YP suffix) and a Visi-Trip indicator for quick fault identification.Specifications
| Brand | Square D |
|---|---|
| Part Number | QBL32225YP |
| Series | QBL |
| Amperage | 225A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Frame Type | QBL |
|---|---|
| Terminal Type | Lugs |
| For Use With | Individual Enclosures, Switchboards, Panelboards (as Main/Sub-feed) |
| Wire Gauge | 4 AWG - 300 kcmil (Al/Cu) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Padlock Attachment |
| Standards | CSA C22.2 No 5, HACR, IEC 60947-2, NEMA AB 1, NOM-003-SCFI-2000, UL 489 |
| Approval | CSA, IEC, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Product FAQs
5 answersWhat does the YP suffix mean on the QBL32225YP?
The YP suffix indicates that the breaker includes a factory-installed handle padlock attachment. This allows the breaker to be locked in either the ON or OFF position to support lockout and tagout safety procedures.
What types of panels and enclosures can the QBL32225YP be installed in?
This Q-frame breaker is designed for use in individual enclosures, switchboards, and panelboards, where it typically functions as a main or sub-feed breaker.
How does the QBL32225YP mount into an electrical system?
It is a unit-mount circuit breaker. Unlike plug-on or I-Line breakers, unit-mount breakers are fastened directly to the mounting surface or backpan and wired using feed-thru lugs.
What wire sizes are accepted by the lugs on this breaker?
The feed-thru lugs on the QBL32225YP accept both aluminum and copper (Al/Cu) conductors ranging from 4 AWG to 300 kcmil.
What type of protection does the trip unit provide?
It features a fixed thermal-magnetic trip unit with long-time and instantaneous (LI) functions, providing reliable protection against sustained overloads and sudden short circuits.
