Eaton / Cutler-Hammer GHB3015 Molded Case Circuit Breaker
- 15A
- 3 Pole
- Bolt-On
Eaton / Cutler-Hammer
GHB3015
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
GHB3015
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer GHB3015 - 15A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Eaton / Cutler-Hammer GHB3015 - 15A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | GHB3015 |
| Series | GHB |
| Amperage | 15A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480Y/277VAC, 125/250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 14kA @ 480Y/277VAC, 14kA @ 125/250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Pow-R-Line Panelboards, Eaton Series C Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 14-10 AWG (Cu/Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, Federal Specification W-C-375B, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Quantity
Eaton / Cutler-Hammer GHB3015 - 15A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | GHB3015-R |
| Series | GHB |
| Amperage | 15A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480Y/277VAC, 125/250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 14kA @ 480Y/277VAC, 14kA @ 125/250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Pow-R-Line Panelboards, Eaton Series C Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 14-10 AWG (Cu/Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, Federal Specification W-C-375B, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Similar Items
20A 3 Pole Molded Case Circuit Breaker
Eaton / Cutler-HammerGHB3020S1
20A 3 Pole Molded Case Circuit Breaker
25A 3 Pole Molded Case Circuit Breaker
Description
Built for three-phase commercial and industrial environments, this 15-amp molded case circuit breaker offers dependable long-time and instantaneous trip functions. The bolt-on design ensures a stable connection within Eaton Pow-R-Line panelboards, Series C switchboards, and motor control centers. Delivering a 14kAIC interrupting capacity at 480Y/277V, the GHB3015 includes load side lugs and a trip-free mechanism that prevents the contacts from being held closed during a fault condition.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | GHB3015 |
| Series | GHB |
| Amperage | 15A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480Y/277VAC, 125/250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 14kA @ 480Y/277VAC, 14kA @ 125/250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Pow-R-Line Panelboards, Eaton Series C Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 14-10 AWG (Cu/Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, Federal Specification W-C-375B, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Product FAQs
6 answersWhich Eaton panelboards are compatible with the GHB3015 breaker?
The GHB3015 is designed for bolt-on installation in Eaton Pow-R-Line 2, 2a, and 2X panelboards. It is also compatible with legacy Pow-R-Line C and Series C switchboards.
Can the Eaton GHB3015 replace older Westinghouse or Cutler-Hammer GHB breakers?
Yes, Eaton acquired both the Westinghouse and Cutler-Hammer distribution equipment lines. The Eaton GHB3015 is the exact engineering replacement for legacy Westinghouse and Cutler-Hammer breakers sharing the same GHB3015 catalog number.
Can the GHB3015 be used on a 480V 3-phase Delta system?
No. Eaton Type GHB circuit breakers are rated for 480Y/277V solid-grounded Wye systems. They are not approved for ungrounded or corner-grounded 3-phase Delta 480V networks.
Is the GHB3015 circuit breaker HACR rated?
Yes, all Eaton Series C G-frame circuit breakers, including the GHB3015, are HACR rated for use with heating, air conditioning, and refrigeration equipment.
Can the GHB3015 be back-fed in a panel?
Yes, the GHB3015 is suitable for reverse feed applications. This allows it to be safely back-fed when required for specific distribution configurations or main breaker setups.
Does the GHB3015 carry an SWD or HID rating for lighting circuits?
No. While single-pole 15A and 20A GHB breakers carry a Switching Duty (SWD) rating, multi-pole versions like the 3-pole GHB3015 do not. High Intensity Discharge (HID) applications require a different factory-modified breaker with an HID catalog suffix.
