Eaton / Cutler-Hammer BRD220230 20/30A Quadplex Miniature Circuit Breaker
- 20/30A
- 4 Pole
- Plug-On
Eaton / Cutler-Hammer
BRD220230
20/30A Quadplex Miniature Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
BRD220230
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer BRD220230 - 20/30A Quadplex Miniature Circuit Breaker
New
Quantity
Similar Items
Eaton / Cutler-HammerBRD2402115
15/40A Quadplex Miniature Circuit Breaker
Eaton / Cutler-HammerBRD220240
20/40A Quadplex Miniature Circuit Breaker
Eaton / Cutler-HammerBRD230240
30/40A Quadplex Miniature Circuit Breaker
Description
Engineered to save valuable enclosure space, the Eaton BRD220230 provides two 20A single-pole outer circuits and one 30A double-pole inner circuit. This quadplex configuration is ideal for residential applications needing extra capacity. Designed as a non-CTL device, it mounts into older Type BR load centers lacking rejection tabs. It serves as an exact replacement for the legacy BQ220230. The outer poles feature independent trip mechanisms, while the inner poles utilize a common trip.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | BRD220230 |
| Series | BRD |
| Amperage | 20/30A |
| Poles | 4 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | BR |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | Type BR Load Centers |
| Wire Gauge | 14-4 AWG Cu/Al |
| Max Wire | 4 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Special Classification | Quadplex |
|---|---|
| Available Options | Padlock Attachment |
| Standards | Federal Specification W-C375, UL 489 |
| Approval | UL |
| Temp Rating | 60 to 75C |
| Construction Features | Non-CTL, HACR Rated, Independent Trip |
Product FAQs
5 answersWhat panels are compatible with the BRD220230 quad breaker?
It is designed for Eaton Type BR load centers and serves as a UL-approved replacement for legacy Westinghouse, Challenger, and Bryant panels that accept Type BR breakers.
How much panel space does the BRD220230 require?
This quadplex breaker requires two standard 1-inch spaces in the panel, providing four circuits in the footprint of a standard two-pole breaker.
What is the pole and amperage configuration of this quad breaker?
The BRD220230 provides two independent 20A single-pole outer circuits and one 30A double-pole common-trip inner circuit.
Is the BRD220230 a CTL or Non-CTL circuit breaker?
This is a Non-CTL breaker without a rejection clip. It is designed to mount into older Type BR load centers that lack rejection tabs.
What legacy catalog numbers does this breaker replace?
The BRD220230 serves as an exact replacement for the legacy Cutler-Hammer BQ220230 quadplex breaker.
