Eaton / Cutler-Hammer PDG12F0080TFFJ Molded Case Circuit Breaker
- 80A
- 2 Pole
- Panel Mount
Eaton / Cutler-Hammer
PDG12F0080TFFJ
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
PDG12F0080TFFJ
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer PDG12F0080TFFJ - 80A 2 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
Eaton / Cutler-HammerPDG13F0080TFFJ
80A 3 Pole Molded Case Circuit Breaker
Eaton / Cutler-HammerPDG13G0080TFFJ
80A 3 Pole Molded Case Circuit Breaker
Eaton / Cutler-HammerPDG13M0080TFFJ
80A 3 Pole Molded Case Circuit Breaker
Description
Built for demanding industrial environments, this 80A two-pole Power Defense breaker utilizes fixed thermal-magnetic trip technology. It integrates into Eaton panelboards and enclosures, serving as an effective upgrade path for legacy FD2080 installations when paired with the appropriate retrofit kit. Featuring a 25kA interrupting capacity at 480VAC, the globally rated MCCB includes standard line and load lugs. Current-limiting performance ensures superior protection for commercial systems.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Series | PDG1 |
| Amperage | 80A |
| Poles | 2 |
| Mounting Style | Panel Mount |
| Voltage | 240VAC, 480VAC, 600Y/347VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 35kA @ 240VAC, 25kA @ 480VAC, 14kA @ 600Y/347VAC, 22kA @ 250VDC |
| Frame Type | Complete Breaker |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | Eaton Power Defense Panelboards, Switchboards, Enclosures |
| Wire Gauge | 14 AWG - 3/0 AWG (Al/Cu) |
| Max Wire | 3/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Auxiliary Switch, Alarm Switch, Shunt Trip, Undervoltage Release, Padlock Attachment, DIN Rail Adapter, Terminal Shields, Interphase Barriers |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489, RoHS Compliant |
| Approval | CCC, CE, CSA, IEC, RoHS, UL |
| Temp Rating | -20C to 70C |
| Construction Features | HACR Rated, Current Limiting, Globally Rated, RoHS Compliant |
Product FAQs
7 answersWhat equipment is the PDG12F0080TFFJ compatible with?
This 80A breaker is designed for use with Eaton Power Defense panelboards, switchboards, and enclosures.
What wire sizes are accepted by the standard box lugs on this breaker?
The standard feed-thru box lugs accept wire gauges from 14 AWG up to 3/0 AWG. They are rated for both aluminum and copper conductors.
Can the PDG12F0080TFFJ be used in DC electrical systems?
Yes, this thermal-magnetic breaker is rated for DC applications up to 250VDC, with an interrupting capacity of 22kAIC.
Are the trip settings adjustable on this 80A breaker?
No, this model features a fixed thermal and fixed magnetic (LI) trip unit, meaning the long-time and instantaneous trip functions cannot be adjusted in the field.
What does the "F" in the PDG12F0080TFFJ catalog number indicate?
The "F" designates the interrupting capacity of the breaker. For this Power Defense Frame 1 model, it indicates a rating of 25kAIC at 480VAC.
Is the PDG12F0080TFFJ a direct replacement for older Eaton breakers?
Yes, the Power Defense PDG1 frame serves as a modern replacement for legacy Eaton Series C FDB and Series G EG frame breakers. An appropriate retrofit kit or updated mounting hardware may be required during installation.
Does this breaker provide ground fault protection?
No, the PDG12F0080TFFJ features a standard thermal-magnetic trip unit with long-time and instantaneous (LI) protection. It does not include ground fault protection or electronic trip functions.
