General Electric TEYL1030B Circuit Breaker
- 30
- 1 Pole
- Bolt-On
General Electric
TEYL1030B
Circuit Breaker
Brand
General Electric
SKU
TEYL1030B
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
General Electric TEYL1030B 1 Pole Circuit Breaker
New
Quantity
Quantity
General Electric TEYL1030B 1 Pole Circuit Breaker
New
Quantity
| Brand | General Electric |
|---|---|
| Part Number | TEYL1030B |
| Series | TEY |
| Amperage | 30 A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 480V |
| Phase | 1 |
| AIC Rating | 100kA @ 120VAC, 65kA @ 277VAC, 15kA @ 125VDC, 100kA @ 120/240VAC |
| Frame Type | TEYL |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE A-Series Lighting Panelboards |
| Wire Gauge | 10-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment |
|---|---|
| Accessories | Load Lugs |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, HID, UL |
| Temp Rating | 40C |
| Construction Features | Current Limiting, HACR Rated, HID Rated, Non-Interchangeable Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Quantity
General Electric TEYL1030B 1 Pole Circuit Breaker
Re-Certified
Quantity
| Brand | General Electric |
|---|---|
| Series | TEY |
| Amperage | 30 A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 480V |
| Phase | 1 |
| AIC Rating | 100kA @ 120VAC, 65kA @ 277VAC, 15kA @ 125VDC, 100kA @ 120/240VAC |
| Frame Type | TEYL |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE A-Series Lighting Panelboards |
| Wire Gauge | 10-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment |
|---|---|
| Accessories | Load Lugs |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, HID, UL |
| Temp Rating | 40C |
| Construction Features | Current Limiting, HACR Rated, HID Rated, Non-Interchangeable Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Similar Items
ABB / General ElectricTEYL1040B
40A 1 Pole Molded Case Circuit Breaker
ABB / General ElectricTEYL1020B
20A 1 Pole Molded Case Circuit Breaker
ABB / General ElectricTEYL1045B
45A 1 Pole Molded Case Circuit Breaker
Description
General Electric TEYL1030B 1 Pole Circuit Breaker
The General Electric TEYL1030B is a 1 Pole thermal magnetic molded case circuit breaker with a current rating of 30 Amps and a voltage rating of 480V. It has an interrupting rating of 65kAIC at 480V. The TEYL1030B has a bolt-on connection type and includes long time and instantaneous trip functions.
Specifications
| Brand | General Electric |
|---|---|
| Part Number | TEYL1030B |
| Series | TEY |
| Amperage | 30 A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 480V |
| Phase | 1 |
| AIC Rating | 100kA @ 120VAC, 65kA @ 277VAC, 15kA @ 125VDC, 100kA @ 120/240VAC |
| Frame Type | TEYL |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE A-Series Lighting Panelboards |
| Wire Gauge | 10-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment |
|---|---|
| Accessories | Load Lugs |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, HID, UL |
| Temp Rating | 40C |
| Construction Features | Current Limiting, HACR Rated, HID Rated, Non-Interchangeable Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Product FAQs
6 answersWhat panelboards are compatible with the TEYL1030B?
This breaker is designed for installation in GE A-Series lighting panelboards (Type AS). It uses a bolt-on mounting base for a secure connection within these enclosures.
What is the difference between the TEYL1030B and other TEY series breakers like the TEYD or TEYH?
The primary difference is the short circuit interrupting rating. While they share the same physical footprint and fit the same A-Series panelboards, the TEYL offers the highest interrupting capacity in the family at 65kAIC at 480V. TEYD and TEYH models offer 25kAIC and 35kAIC, respectively.
Can the TEYL1030B be reverse fed?
Yes, TEYL series circuit breakers are suitable for reverse feed applications.
Is the TEYL1030B rated for HVAC or high-intensity lighting applications?
Yes, this breaker is HACR rated for use with heating, air conditioning, and refrigeration equipment. It is also HID rated for high-intensity discharge lighting circuits.
Will this breaker be branded as GE or ABB?
Following ABB acquiring GE Industrial Solutions, this breaker may arrive with either GE or ABB branding depending on the production date. The physical footprint, specifications, and panelboard compatibility remain identical regardless of the label.
Does the TEYL1030B provide ground fault or arc fault protection?
No, this is a standard thermal magnetic circuit breaker. It provides standard overload and short circuit protection but does not include GFCI or AFCI capabilities.
