ABB / General Electric THED136100WL Molded Case Circuit Breaker
- 100A
- 3 Pole
- Unit Mount
ABB / General Electric
THED136100WL
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
THED136100WL
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric THED136100WL - 100A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
ABB / General Electric THED136100WL - 100A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | THED136100WL |
| Series | THED |
| Amperage | 100A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC, 500VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC, 10kA @ 500VDC |
| Frame Type | TED |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Enclosures, Switchboards, Motor Control Centers |
| Wire Gauge | 3 AWG - 3/0 AWG (Cu), 1 AWG - 3/0 AWG (Al) |
| Max Wire | 3/0 AWG |
| Min Wire | 3 AWG (Cu), 1 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Line and Load Lugs (TCAL15) |
| Standards | CSA C22.2 No. 5.1, HACR Rated, NEMA AB 1, UL 489, IEC 60947-2 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Reverse Feed, Non-Interchangeable Trip, Common Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Quantity
ABB / General Electric THED136100WL - 100A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | THED136100WL-R |
| Series | THED |
| Amperage | 100A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC, 500VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC, 10kA @ 500VDC |
| Frame Type | TED |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Enclosures, Switchboards, Motor Control Centers |
| Wire Gauge | 3 AWG - 3/0 AWG (Cu), 1 AWG - 3/0 AWG (Al) |
| Max Wire | 3/0 AWG |
| Min Wire | 3 AWG (Cu), 1 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Line and Load Lugs (TCAL15) |
| Standards | CSA C22.2 No. 5.1, HACR Rated, NEMA AB 1, UL 489, IEC 60947-2 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Reverse Feed, Non-Interchangeable Trip, Common Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Similar Items
ABB / General ElectricTHED136090WL
90A 3 Pole Molded Case Circuit Breaker
ABB / General ElectricTHED136080WL
80A 3 Pole Molded Case Circuit Breaker
ABB / General ElectricTHED136125WL
125A 3 Pole Molded Case Circuit Breaker
Description
Featuring factory-installed line and load lugs, the THED136100WL provides versatile unit-mount installation for GE enclosures and switchboards. Part of the E150 frame family, this 3-pole, 100A molded case circuit breaker delivers reliable thermal-magnetic protection with a 65kAIC rating at 240V and 18kAIC at 600V. Ideal for motor control centers, this breaker features a trip-free mechanism and is HACR rated. It serves as a direct upgrade for the legacy TED136100WL standard-interrupt model.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | THED136100WL |
| Series | THED |
| Amperage | 100A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC, 500VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC, 10kA @ 500VDC |
| Frame Type | TED |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Enclosures, Switchboards, Motor Control Centers |
| Wire Gauge | 3 AWG - 3/0 AWG (Cu), 1 AWG - 3/0 AWG (Al) |
| Max Wire | 3/0 AWG |
| Min Wire | 3 AWG (Cu), 1 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Line and Load Lugs (TCAL15) |
| Standards | CSA C22.2 No. 5.1, HACR Rated, NEMA AB 1, UL 489, IEC 60947-2 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Reverse Feed, Non-Interchangeable Trip, Common Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Product FAQs
5 answersWill my THED136100WL breaker arrive with GE or ABB branding?
Because ABB acquired GE Industrial Solutions, this E-150 line breaker may feature either ABB or GE branding. The physical dimensions, mounting, and electrical specifications remain completely identical regardless of the label.
What does the "WL" suffix mean on this GE circuit breaker?
The "WL" suffix indicates that the breaker comes equipped with factory-installed line and load lugs. These plated aluminum lugs are ready to accept either copper or aluminum conductors.
How does the THED136100WL mount into a panel?
This is a unit-mount breaker, meaning it bolts directly into place rather than snapping onto a busbar or clipping onto a DIN rail. It is designed specifically for hardwired installations in compatible GE enclosures, switchboards, and motor control centers.
Is this breaker suitable for direct current (DC) systems?
Yes. While commonly used for AC distribution, its fixed thermal-magnetic trip unit is also rated for DC applications, providing up to 10kA of interrupting capacity on 250VDC and 500VDC circuits.
Are the trip settings on the THED136100WL adjustable?
No, this breaker features a fixed thermal and fixed magnetic trip unit. The long-time and instantaneous (LI) protection parameters are factory-set and cannot be adjusted in the field.
