ABB / General Electric TMQD32100 Molded Case Circuit Breaker
- 100A
- 3 Pole
- Bolt-On
ABB / General Electric
TMQD32100
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
TMQD32100
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric TMQD32100 - 100A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
ABB / General Electric TMQD32100 - 100A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | TMQD32100 |
| Series | TMQD |
| Amperage | 100A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 208Y/120VAC, 240VAC |
| Phase | 3 |
| AIC Rating | 100kA @ 208Y/120VAC, 100kA @ 240VAC |
| Frame Type | TMQD |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Meter Mod Meter Stacks, GE Panelboards |
| Wire Gauge | 6 AWG - 1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 6 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Extra High Interrupting Capacity, Non-Interchangeable Trip, Tenant Main |
Quantity
ABB / General Electric TMQD32100 - 100A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | TMQD32100 |
| Series | TMQD |
| Amperage | 100A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 208Y/120VAC, 240VAC |
| Phase | 3 |
| AIC Rating | 100kA @ 208Y/120VAC, 100kA @ 240VAC |
| Frame Type | TMQD |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Meter Mod Meter Stacks, GE Panelboards |
| Wire Gauge | 6 AWG - 1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 6 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Extra High Interrupting Capacity, Non-Interchangeable Trip, Tenant Main |
Similar Items
ABB / General ElectricTMQD32060
60A 3 Pole Molded Case Circuit Breaker
ABB / General ElectricTMQD32150
150A 3 Pole Molded Case Circuit Breaker
ABB / General ElectricTMQD32175
175A 3 Pole Molded Case Circuit Breaker
Description
Designed for high-capacity tenant main applications, the GE TMQD32100 is a 100A, 3-pole molded case circuit breaker. It integrates seamlessly into GE Meter Mod meter stacks and panelboards, utilizing a secure bolt-on mounting style. The breaker features a non-interchangeable thermal-magnetic trip unit that delivers precise long-time and instantaneous protection. With a robust 100kAIC rating at 240VAC, it provides exceptional fault isolation for commercial and industrial facilities.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TMQD32100 |
| Series | TMQD |
| Amperage | 100A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 208Y/120VAC, 240VAC |
| Phase | 3 |
| AIC Rating | 100kA @ 208Y/120VAC, 100kA @ 240VAC |
| Frame Type | TMQD |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Meter Mod Meter Stacks, GE Panelboards |
| Wire Gauge | 6 AWG - 1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 6 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Extra High Interrupting Capacity, Non-Interchangeable Trip, Tenant Main |
Product FAQs
7 answersWhich panelboards and enclosures accept the TMQD32100?
This breaker is designed for installation in GE Meter Mod meter stacks, often as a tenant main disconnect, as well as compatible GE panelboards that accept bolt-on Q-Line breakers.
What applications require the 100kAIC rating of the TMQD32100?
The 100kAIC interrupting capacity is required in commercial and industrial distribution systems where the available fault current exceeds standard 10kAIC or 22kAIC limits. This ensures the breaker can safely clear severe short circuits without catastrophic failure.
What wire sizes and conductor materials are supported by the TMQD32100 lugs?
The factory lugs accommodate wire gauges from 6 AWG up to 1/0 AWG. They are dual-rated for both copper (Cu) and aluminum (Al) conductors.
How does the TMQD32100 differ from THQD or TQD breakers?
While TQD, THQD, and TMQD breakers share the same physical frame size and bolt-on mounting, their interrupting ratings differ. TQD is rated at 10kAIC, THQD is rated at 22kAIC, and TMQD is rated for extra-high fault applications at 100kAIC.
How does the thermal-magnetic trip unit in the TMQD32100 operate?
The fixed thermal-magnetic mechanism provides dual protection. The thermal component responds to sustained overloads by heating a bimetallic strip, while the magnetic component provides an instantaneous (LI) trip response to clear severe short circuits immediately.
Can the trip settings on the TMQD32100 be adjusted in the field?
No, this breaker features a fixed thermal and fixed magnetic trip unit. The long-time and instantaneous trip functions are factory calibrated and cannot be modified.
Does the TMQD32100 require a specific mounting kit for panel installation?
When installing in certain GE panelboards or meter modules, a dedicated breaker mounting kit, such as the TMTQD3 for 3-pole configurations, may be required to secure the breaker to the bus bars.
