Eaton / Cutler-Hammer HFB3040 Molded Case Circuit Breaker
- 40A
- 3 Pole
- Bolt-On
Eaton / Cutler-Hammer
HFB3040
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
HFB3040
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer HFB3040 - 40A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
30A 3 Pole Molded Case Circuit Breaker
25A 3 Pole Molded Case Circuit Breaker
60A 3 Pole Molded Case Circuit Breaker
Description
Operating as a core component in commercial power distribution, this 40-amp, 3-pole breaker utilizes fixed thermal-magnetic trip technology. The F-Frame design accommodates a wide range of industrial voltages up to 600VAC. Installation is straightforward for facilities using Eaton Pow-R-Line C panelboards or motor control centers. It also provides a reliable replacement path for aging Westinghouse F-Frame switchboards. This Mark 75 series unit boasts a 65kAIC rating at 240V and is HACR rated.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | HFB3040-R |
| Series | HFB |
| Amperage | 40A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 20kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Pow-R-Line C Panelboards, Westinghouse Panelboards, Switchboards |
| Wire Gauge | 14-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs |
| Standards | NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Non-Interchangeable Trip |
Product FAQs
5 answersWhat panelboards are compatible with the HFB3040 circuit breaker?
This F-frame breaker is designed for use in Eaton Pow-R-Line C panelboards, legacy Westinghouse panelboards, and compatible switchboards.
Can the Eaton HFB3040 replace an older Westinghouse HFB3040?
Yes. Eaton acquired the Westinghouse distribution equipment business. This breaker is a direct physical and electrical replacement for legacy Westinghouse HFB breakers of the same style and rating.
What is the difference between Eaton FB and HFB circuit breakers?
The HFB series is the Mark 75 high-interrupting capacity version of the standard FB breaker. While they share the same physical F-frame dimensions, the HFB provides higher fault protection, such as 65kA at 240VAC.
How is the HFB3040 applied in direct current (DC) systems?
It is rated for up to 250VDC at 20kA. To safely interrupt DC faults, the manufacturer requires the breaker poles to be wired in series. Standard parallel wiring across independent DC circuits is not permitted.
Are the trip settings on the HFB3040 adjustable?
No, this breaker features a thermal-magnetic trip unit with fixed long-time (thermal) and fixed instantaneous (magnetic) trip functions. The trip points cannot be adjusted in the field.
