Square D QO370VH Miniature Circuit Breaker
- 70A
- 3 Pole
- Plug-On
Square D
QO370VH
Miniature Circuit Breaker
Brand
Square D
SKU
QO370VH
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D QO370VH - 70A 3 Pole Miniature Circuit Breaker
New
Quantity
Similar Items
50A 3 Pole Miniature Circuit Breaker
100A 3 Pole Miniature Circuit Breaker
40A 3 Pole Miniature Circuit Breaker
Description
Part of the QO series, the QO370VH is a 3-pole, 70A miniature circuit breaker designed for environments requiring elevated fault protection. It features a high interrupting capacity rated at 22kAIC at 240VAC. This plug-on breaker mounts into Square D QO load centers, NQ panelboards, and Speed-D switchboards. It accepts 8-2 AWG aluminum or copper wiring. Built with thermal-magnetic trip technology, it ensures reliable defense against overloads.Specifications
| Brand | Square D |
|---|---|
| Part Number | QO370VH |
| Series | QO |
| Amperage | 70A |
| Poles | 3 |
| Mounting Style | Plug-On |
| Voltage | 240VAC, 120/240VAC |
| Phase | 3 |
| AIC Rating | 22kA @ 240VAC, 22kA @ 120/240VAC |
| Frame Type | QO |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | QO Load Centers, NQ Panelboards, Speed-D Switchboards |
| Wire Gauge | 8-2 AWG (Al/Cu) |
| Max Wire | 2 AWG |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Auxiliary Switch, Alarm Switch, Padlock Attachment, Shunt Trip |
|---|---|
| Standards | CSA C22.2 No. 5, UL 489, HACR |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | Visual Trip Indicator, HACR Rated, High Interrupting Capacity, Mercury Free, Common Trip |
Product FAQs
5 answersCan I install the QO370VH in a standard residential QO load center?
No. The QO370VH is a 3-pole breaker designed for 3-phase systems. Most standard residential QO load centers are single-phase and cannot accommodate a 3-pole breaker. You must use a compatible 3-phase QO load center, NQ panelboard, or Speed-D switchboard.
What does the "VH" suffix indicate on the QO370VH?
The "VH" suffix designates a high interrupting rating. While a standard QO370 is rated for 10kAIC, the QO370VH is rated for 22kAIC at 120/240VAC, making it suitable for commercial or industrial applications with higher available fault currents.
How much panel space is required to install the QO370VH?
As a 3-pole miniature circuit breaker, the QO370VH requires three standard 3/4-inch spaces in a compatible Square D panelboard or load center.
What is the bolt-on equivalent to the QO370VH?
If your panel requires a bolt-on connection rather than a plug-on connection, you will need the QOB equivalent. The direct bolt-on replacement is the QOB370VH.
How can I tell if the QO370VH has tripped?
The QO370VH features Square D Visi-Trip technology. When the breaker trips due to an overcurrent or short circuit, the handle snaps to a center position and a bright red indicator appears in a window on the breaker face, allowing for quick identification in a crowded panel.
