Siemens 3VA6460-6HN31-0AA0 Molded Case Circuit Breaker
- 600A
- 3 Pole
- Panel Mount
Siemens
3VA6460-6HN31-0AA0
Molded Case Circuit Breaker
Brand
Siemens
SKU
3VA6460-6HN31-0AA0
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens 3VA6460-6HN31-0AA0 - 600A 3 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
1200A 3 Pole Molded Case Circuit Breaker
1200A 3 Pole Molded Case Circuit Breaker
1200A 3 Pole Molded Case Circuit Breaker
Description
The Siemens 3VA6460-6HN31-0AA0 is a high-performance 600A, 3-pole molded case circuit breaker built for robust commercial and industrial applications. It is engineered for panel mount configurations, fitting seamlessly into Siemens P3, P4, and P5 panelboards, switchboards, and motor control centers. It serves as a substitute for the 3VA6460-7HN31-0AA0. Equipped with an ETU350 electronic trip unit, it provides adjustable long-time, short-time, and instantaneous (LSI) protection at 65 kAIC.Specifications
| Brand | Siemens |
|---|---|
| Part Number | 3VA6460-6HN31-0AA0 |
| Series | 3VA6 |
| Amperage | 600A |
| Poles | 3 |
| Mounting Style | Panel Mount |
| Voltage | 240VAC, 480Y/277VAC, 480VAC, 600Y/347VAC, 600VAC |
| Phase | 3 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480Y/277VAC, 65kA @ 480VAC, 22kA @ 600Y/347VAC, 22kA @ 600VAC |
| Amperage Range | 240-600A |
|---|
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens P3, P4, P5 Panelboards, Switchboards, Motor Control Centers |
| Trip Technology | Electronic Trip |
|---|---|
| Trip Function Code | LSI |
| Trip Function | Long-Time, Short-Time, Instantaneous |
| Trip Adjustability | Adjustable |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator, Rotary Handle, Lug Kits |
|---|---|
| Accessories | Nut Keeper Kit |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CE, CSA, cULus, IEC, UL, VDE |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Reverse Feed, 80% Rated, Non-Interchangeable Trip |
Product FAQs
5 answersWhich panelboards accept the 3VA6460-6HN31-0AA0 circuit breaker?
This 600A breaker mounts seamlessly into Siemens P3, P4, and P5 panelboards. It is also compatible with Siemens switchboards and motor control centers.
What adjustability does the ETU350 LSI trip unit provide?
The solid-state ETU350 allows for precise field-adjustable Long-Time, Short-Time, and Instantaneous trip settings. The overload protection range can be adjusted from 240A to 600A to ensure proper selective coordination.
Is the trip unit on the 3VA6460-6HN31-0AA0 interchangeable?
No, this breaker is manufactured with a factory-installed, non-interchangeable ETU350 electronic trip unit.
Can the 3VA6460-6HN31-0AA0 be reverse fed?
Yes, this molded case circuit breaker is rated for reverse feed applications. It is an 80 percent rated breaker and carries a standard HACR rating for commercial and industrial use.
What does the Class H breaking capacity indicate on this 3VA6 frame?
The Class H designation signifies a high interrupting capacity, delivering 65kAIC at 480V and 22kAIC at 600V for demanding distribution networks.
