Siemens ED22B080 Molded Case Circuit Breaker
- 80A
- 2 Pole
- Bolt-On
Siemens
ED22B080
Molded Case Circuit Breaker
Brand
Siemens
SKU
ED22B080
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens ED22B080 - 80A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens ED22B080 - 80A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | ED22B080 |
| Series | ED2 |
| Amperage | 80A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC, 5kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, SB Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release, Padlock Attachment, Lug Kits |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, HACR Rated, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Non-Interchangeable Trip |
Quantity
Siemens ED22B080 - 80A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | ED22B080-R |
| Series | ED2 |
| Amperage | 80A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC, 5kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, SB Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release, Padlock Attachment, Lug Kits |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, HACR Rated, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Non-Interchangeable Trip |
Similar Items
70A 2 Pole Molded Case Circuit Breaker
100A 2 Pole Molded Case Circuit Breaker
60A 2 Pole Molded Case Circuit Breaker
Description
Engineered for the ED2 frame, the ED22B080 delivers dependable thermal-magnetic protection for commercial power systems. This 80A, two-pole molded case circuit breaker ensures consistent performance under demanding conditions. The bolt-on design mounts into Siemens P1, P2, and P3 panelboards, plus SB switchboards. It includes load side lugs compatible with 10-1/0 AWG conductors and features a fixed trip unit. With a 10 kAIC rating at 240VAC, this HACR-rated breaker meets UL 489 standards.Specifications
| Brand | Siemens |
|---|---|
| Part Number | ED22B080 |
| Series | ED2 |
| Amperage | 80A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC, 5kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, SB Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release, Padlock Attachment, Lug Kits |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, HACR Rated, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Non-Interchangeable Trip |
Product FAQs
6 answersWhich Siemens panelboards accept the ED22B080 circuit breaker?
The ED22B080 bolt-on breaker is compatible with Siemens P1, P2, and P3 panelboards, as well as SB switchboards. Installation requires the correct ED frame mounting kit for your specific panel enclosure.
What is the difference between Siemens ED2, ED4, and ED6 circuit breakers?
The primary difference is the maximum voltage rating. ED2 breakers, such as the ED22B080, are rated for up to 240VAC. ED4 breakers are rated for up to 480VAC, and ED6 breakers handle up to 600VAC. They all share the same physical ED frame footprint.
Do I need a mounting kit to install the ED22B080 in a P1 panelboard?
Yes, installing this ED frame breaker as a main or subfeed device in a Siemens P1 panelboard requires a dedicated mounting kit, such as the MBKED1 for single-phase or MBKED3 for three-phase original P1 panels. You must verify your panel generation (Original vs. Revised P1) to select the correct kit.
Can the ED22B080 be used in direct current (DC) applications?
Yes, this thermal-magnetic breaker is rated for DC systems up to 250VDC, providing a 5kA interrupting capacity. It is suitable for direct current applications provided the wiring configuration follows Siemens DC application guidelines.
Can the Siemens ED22B080 be reverse fed?
Yes, standard Siemens ED frame breakers like the ED22B080 have non-interchangeable trip units and are suitable for reverse feeding according to UL 489 standards, provided there are no specific LINE and LOAD markings restricting power flow direction.
Can the ED22B080 handle be locked in the OFF position?
Yes, you can install a handle blocking device or padlock attachment (such as the ED2HPL) on ED frame breakers to lock the handle in the OFF position for safe maintenance and lockout-tagout compliance.
