Siemens ED61B015 Molded Case Circuit Breaker
- 15A
- 1 Pole
- Bolt-On
Siemens
ED61B015
Molded Case Circuit Breaker
Brand
Siemens
SKU
ED61B015
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens ED61B015 - 15A 1 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
40A 1 Pole Molded Case Circuit Breaker
45A 1 Pole Molded Case Circuit Breaker
50A 1 Pole Molded Case Circuit Breaker
Description
Operating on 347VAC systems, the Siemens ED61B015 is a 1-pole, 15A molded case circuit breaker. Belonging to the Sentron ED6 frame family, it provides dependable thermal-magnetic overcurrent protection for commercial and industrial facilities. This bolt-on MCCB installs into Siemens P1, P2, and P3 panelboards, as well as compatible switchboards. It accepts 14-10 AWG copper wire via standard lugs. The breaker delivers a 30kAIC rating at 347V. It is HACR rated and reverse feed capable.Specifications
| Brand | Siemens |
|---|---|
| Part Number | ED61B015 |
| Series | ED6 |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 347VAC |
| Phase | 1 |
| AIC Rating | 30kA @ 347VAC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 14-10 AWG (Cu), 12-10 AWG (Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG (Cu) / 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
6 answersWhich panelboards are compatible with the Siemens ED61B015 circuit breaker?
The ED61B015 is a bolt-on MCCB designed for installation in Siemens P1, P2, and P3 panelboards, as well as compatible Siemens switchboards and motor control centers.
What are the lug torque specifications for the ED61B015?
The breaker comes equipped with SA1E025 load lugs. When terminating 14 to 10 AWG copper or 12 to 10 AWG aluminum conductors, tighten the lugs to 32 lb-in.
Can the Siemens ED61B015 be reverse fed?
Yes. Because it features a non-interchangeable thermal-magnetic trip unit, the ED61B015 is suitable for reverse feed applications in accordance with UL 489 requirements.
Is the ED61B015 breaker HACR rated?
Yes, this breaker carries an HACR rating, making it approved for overcurrent protection on heating, air conditioning, and refrigeration equipment.
What is the difference between the Siemens ED41B015 and ED61B015?
The primary difference is the voltage rating. The ED41B015 is a 1-pole breaker rated for 277VAC, while the ED61B015 is rated for 347VAC. Both share the same 15A ED frame footprint.
What are the physical dimensions of the ED61B015?
This 1-pole ED frame breaker measures approximately 6.4 inches high, 1.0 inch wide, and 3.92 inches deep.
