Siemens HHED62B025 Molded Case Circuit Breaker
- 25A
- 2 Pole
- Bolt-On
Siemens
HHED62B025
Molded Case Circuit Breaker
Brand
Siemens
SKU
HHED62B025
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens HHED62B025 - 25A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens HHED62B025 - 25A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | HHED62B025 |
| Series | HHED6 |
| Amperage | 25A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | HHED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Sentron Panelboards (P1, P2, P3), Switchboards, Enclosures |
| Wire Gauge | 14-10 AWG (Cu), 12-10 AWG (Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG (Cu) / 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Lugs (SA1E025) |
| Standards | CSA C22.2 No. 5, HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Extra High Interrupting Capacity, Non-Interchangeable Trip, Reverse Feed |
Sold out
Quantity
Siemens HHED62B025 - 25A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | HHED62B025-R |
| Series | HHED6 |
| Amperage | 25A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | HHED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Sentron Panelboards (P1, P2, P3), Switchboards, Enclosures |
| Wire Gauge | 14-10 AWG (Cu), 12-10 AWG (Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG (Cu) / 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Lugs (SA1E025) |
| Standards | CSA C22.2 No. 5, HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Extra High Interrupting Capacity, Non-Interchangeable Trip, Reverse Feed |
Similar Items
20A 2 Pole Molded Case Circuit Breaker
15A 2 Pole Molded Case Circuit Breaker
40A 2 Pole Molded Case Circuit Breaker
Description
Built to handle demanding commercial and industrial loads, the HHED62B025 is a 25-amp, 2-pole molded case circuit breaker. It features an extra high interrupting rating of 65kA at 480V and 100kA at 240V, ensuring robust thermal-magnetic protection. The breaker mounts into Siemens Sentron P1, P2, and P3 panelboards, as well as standard enclosures. For facility upgrades, be aware that this ED frame model is replaced by the 3VA5125-6EC21-0AA0, which requires a separate mounting kit.Specifications
| Brand | Siemens |
|---|---|
| Part Number | HHED62B025 |
| Series | HHED6 |
| Amperage | 25A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | HHED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Sentron Panelboards (P1, P2, P3), Switchboards, Enclosures |
| Wire Gauge | 14-10 AWG (Cu), 12-10 AWG (Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG (Cu) / 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Lugs (SA1E025) |
| Standards | CSA C22.2 No. 5, HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Extra High Interrupting Capacity, Non-Interchangeable Trip, Reverse Feed |
Product FAQs
5 answersWhat panels are compatible with the Siemens HHED62B025?
The HHED62B025 is designed for use in Siemens Sentron panelboards, specifically P1, P2, and P3 models. It is also compatible with Siemens switchboards and enclosures designed to accept ED frame circuit breakers.
Can the Siemens HHED62B025 replace an older I-T-E breaker with the same catalog number?
Yes. Siemens acquired I-T-E, and the modern Siemens HHED62B025 serves as a direct form, fit, and functional replacement for legacy I-T-E breakers sharing the exact same catalog number.
What lug kit is standard for the HHED62B025?
The standard lug kit for this 25A ED frame breaker is the SA1E025. These lugs accommodate 14-10 AWG copper or 12-10 AWG aluminum conductors.
Is the HHED62B025 suitable for reverse feed applications?
Yes. Siemens ED frame molded case circuit breakers, including the HHED62B025, are suitable for reverse feed installations.
What does the HH prefix in the HHED62B025 catalog number indicate?
The HH prefix designates the interrupting rating tier within the Siemens ED frame family. The HHED6 series provides a high interrupting capacity of 65kAIC at 480VAC and 100kAIC at 240VAC.
