Square D EDB26040 Molded Case Circuit Breaker
- 40A
- 2 Pole
- Bolt-On
Square D
EDB26040
Molded Case Circuit Breaker
Brand
Square D
SKU
EDB26040
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D EDB26040 - 40A 2 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
30A 2 Pole Molded Case Circuit Breaker
30A 2 Pole Molded Case Circuit Breaker
60A 2 Pole Molded Case Circuit Breaker
Description
Part of the E-Frame family, this 40A commercial breaker delivers robust thermal-magnetic protection for industrial electrical systems. It features a built-in Visi-Trip indicator to quickly identify tripped circuits during maintenance. The bolt-on design installs into Square D NF panelboards, ensuring a secure connection for 277/480Y VAC distribution networks. Rated at 18 kAIC for 480Y/277V applications, it carries both HACR and HID classifications for specialized lighting and HVAC loads.Specifications
| Brand | Square D |
|---|---|
| Series | EDB |
| Amperage | 40A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 240VAC, 277VAC, 480Y/277VAC, 600Y/347VAC, 120/240VAC |
| Phase | 1 |
| AIC Rating | 25kA @ 120VAC, 25kA @ 240VAC, 18kA @ 277VAC, 18kA @ 480Y/277VAC, 14kA @ 600Y/347VAC, 25kA @ 120/240VAC |
| Frame Type | EDB |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D NF Panelboards |
| Wire Gauge | 14-2/0 AWG (Cu), 12-2/0 AWG (Al) |
| Max Wire | 2/0 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Aluminum Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, cULus, HACR, HID, NOM, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, HID Rated, Visual Trip Indicator |
Product FAQs
6 answersWhat panelboards are compatible with the Square D EDB26040?
The EDB26040 is an E-frame circuit breaker designed exclusively for use in Square D NF panelboards. It is not compatible with NQ or QO series panelboards.
What is the difference between the EDB26040, EGB26040, and EJB26040?
All three are 40A, 2-pole E-frame breakers for NF panelboards, but they offer different interrupting ratings. The EDB is the standard tier (18kA at 480Y/277VAC), the EGB is the high-interrupting tier (35kA at 480Y/277VAC), and the EJB is the extra-high tier (65kA at 480Y/277VAC).
Is the EDB26040 circuit breaker HACR rated?
Yes, this E-frame breaker is HACR rated, meaning it is approved for branch circuit protection of heating, air conditioning, and refrigeration equipment.
Can the EDB26040 be mounted on a standard DIN rail?
No, this is a bolt-on circuit breaker. It is designed to bolt directly to the interior busbars of a Square D NF panelboard and cannot be installed on a DIN rail.
Does the EDB26040 include equipment ground fault protection?
No, this model features standard thermal-magnetic trip functions for overload and short-circuit protection. Square D E-frame breakers that include 30mA equipment ground fault protection will have an EPD suffix in the catalog number.
Does the EDB26040 feature a visual trip indicator?
Yes, Square D E-frame breakers include the Visi-Trip indicator. When the breaker trips, the handle moves to a center position and a red indicator appears, allowing electricians to quickly identify the faulted circuit in a crowded panel.
