Square D JGA36175 Molded Case Circuit Breaker
- 175A
- 3 Pole
- I-Line
Square D
JGA36175
Molded Case Circuit Breaker
Brand
Square D
SKU
JGA36175
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D JGA36175 - 175A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Square D JGA36175 - 175A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | JGA36175 |
| Series | JGA |
| Amperage | 175A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC, 500VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 18kA @ 600VAC, 20kA @ 250VDC, 20kA @ 500VDC |
| Frame Type | JGA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, I-Line Switchboards |
| Wire Gauge | 4 AWG - 4/0 AWG (Al/Cu) |
| Max Wire | 4/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Rotary Handle, Lug Kits |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CCC, CE, CSA, IEC, NOM, UKCA, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Visual Trip Indicator, Mercury Free, PVC Free, 80% Rated |
Quantity
Square D JGA36175 - 175A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | JGA36175-R |
| Series | JGA |
| Amperage | 175A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC, 500VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 18kA @ 600VAC, 20kA @ 250VDC, 20kA @ 500VDC |
| Frame Type | JGA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, I-Line Switchboards |
| Wire Gauge | 4 AWG - 4/0 AWG (Al/Cu) |
| Max Wire | 4/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Rotary Handle, Lug Kits |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CCC, CE, CSA, IEC, NOM, UKCA, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Visual Trip Indicator, Mercury Free, PVC Free, 80% Rated |
Similar Items
200A 3 Pole Molded Case Circuit Breaker
150A 3 Pole Molded Case Circuit Breaker
225A 3 Pole Molded Case Circuit Breaker
Description
Designed for heavy-duty power distribution, the Square D JGA36175 is a 175A, 3-pole molded case circuit breaker from the PowerPacT J-Frame series. It delivers robust thermal-magnetic protection for commercial and industrial facilities. This component mounts into Square D I-Line panelboards and switchboards. It is an exact substitute for the discontinued KA36175, ensuring a seamless upgrade path. Rated 35kAIC at 480VAC, it features a Visi-Trip indicator and current-limiting capabilities.Specifications
| Brand | Square D |
|---|---|
| Part Number | JGA36175 |
| Series | JGA |
| Amperage | 175A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC, 500VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 18kA @ 600VAC, 20kA @ 250VDC, 20kA @ 500VDC |
| Frame Type | JGA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, I-Line Switchboards |
| Wire Gauge | 4 AWG - 4/0 AWG (Al/Cu) |
| Max Wire | 4/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Rotary Handle, Lug Kits |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CCC, CE, CSA, IEC, NOM, UKCA, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Visual Trip Indicator, Mercury Free, PVC Free, 80% Rated |
Product FAQs
7 answersCan I use the JGA36175 to replace a legacy KA36175 circuit breaker?
Yes. The PowerPact J-Frame JGA36175 is the direct, modernized replacement for the obsolete KA-Frame KA36175 breaker. It mounts into the exact same I-Line panelboards and offers equivalent or superior interrupting capabilities.
How do I decipher the JGA36175 catalog number?
The "J" designates the PowerPact J-Frame. "G" represents the interrupting rating tier. "A" indicates an I-Line style plug-in connection. The "3" means three-pole, the "6" indicates a 600V maximum voltage rating, and "175" specifies the 175-amp trip rating.
Is the JGA36175 trip unit field-interchangeable?
No. This specific breaker features a factory-sealed thermal-magnetic trip unit. If you require a different amperage or trip characteristic, the entire breaker must be replaced, or you must select a unit-mount frame specifically configured for field-interchangeable units.
Do I need a mounting adapter to install this breaker in an older I-Line panel?
No. The JGA36175 is a standard I-Line plug-in breaker. Its integral mounting bracket and plug-on jaws are designed to snap directly onto the bus of both legacy and modern Square D I-Line panelboards and switchboards without adapters.
Does the JGA36175 require an external load lug kit?
No. The breaker comes factory-equipped with line-side plug-on jaws for the I-Line bus and standard mechanical load lugs (part number AL175JD) built-in. These standard lugs accept both aluminum and copper wire within the specified gauge range.
Is the JGA36175 rated for 100 percent continuous loads?
No. Like all standard PowerPact J-Frame I-Line breakers, the JGA36175 is rated for 80 percent continuous loads. Square D does not offer 100 percent rated options in the I-Line plug-in configuration.
What is the purpose of the push-to-trip button on the breaker face?
The push-to-trip button allows you to manually exercise the breaker's mechanical tripping system. Regularly testing this function ensures the internal mechanism operates freely, which is a recommended maintenance practice for electrical safety.
