Square D JGA36200 Molded Case Circuit Breaker
- 200A
- 3 Pole
- I-Line
Square D
JGA36200
Molded Case Circuit Breaker
Brand
Square D
SKU
JGA36200
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D JGA36200 - 200A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Square D JGA36200 - 200A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | JGA36200 |
| Series | JGA |
| Amperage | 200A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC, 500VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 18kA @ 600VAC, 20kA @ 250VDC, 20kA @ 500VDC |
| Frame Type | JGA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, I-Line Switchboards |
| Wire Gauge | 3/0 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Auxiliary Switch, Alarm Switch, Shunt Trip, Undervoltage Release, Padlock Attachment, Motor Operator |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CCC, CE, CSA, IEC, NOM, UKCA, UL |
| Temp Rating | -25C to 70C |
| Construction Features | Current Limiting, HACR Rated, Visual Trip Indicator, Mercury Free, PVC Free, RoHS Compliant |
Quantity
Square D JGA36200 - 200A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | JGA36200-R |
| Series | JGA |
| Amperage | 200A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC, 500VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 18kA @ 600VAC, 20kA @ 250VDC, 20kA @ 500VDC |
| Frame Type | JGA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, I-Line Switchboards |
| Wire Gauge | 3/0 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Auxiliary Switch, Alarm Switch, Shunt Trip, Undervoltage Release, Padlock Attachment, Motor Operator |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CCC, CE, CSA, IEC, NOM, UKCA, UL |
| Temp Rating | -25C to 70C |
| Construction Features | Current Limiting, HACR Rated, Visual Trip Indicator, Mercury Free, PVC Free, RoHS Compliant |
Similar Items
175A 3 Pole Molded Case Circuit Breaker
175A 3 Pole Molded Case Circuit Breaker
250A 3 Pole Molded Case Circuit Breaker
Description
Built for heavy-duty power distribution, the Square D JGA36200 is a 3-pole, 200A PowerPacT J-Frame MCCB. It utilizes thermal-magnetic trip technology to deliver precise Long-Time and Instantaneous (LI) protection for industrial facilities. This breaker mounts into Square D I-Line panelboards and switchboards. It can also be used as a replacement for the older KA36200 breaker. With a 35kAIC rating at 480VAC, it safely handles high fault currents and includes a Visi-Trip indicator.Specifications
| Brand | Square D |
|---|---|
| Part Number | JGA36200 |
| Series | JGA |
| Amperage | 200A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC, 500VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 18kA @ 600VAC, 20kA @ 250VDC, 20kA @ 500VDC |
| Frame Type | JGA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, I-Line Switchboards |
| Wire Gauge | 3/0 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Auxiliary Switch, Alarm Switch, Shunt Trip, Undervoltage Release, Padlock Attachment, Motor Operator |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CCC, CE, CSA, IEC, NOM, UKCA, UL |
| Temp Rating | -25C to 70C |
| Construction Features | Current Limiting, HACR Rated, Visual Trip Indicator, Mercury Free, PVC Free, RoHS Compliant |
Product FAQs
5 answersWhich panelboards are compatible with the JGA36200 circuit breaker?
The JGA36200 is an I-Line style breaker designed strictly for Square D I-Line panelboards and switchboards. It will not mount in standard unit-mount enclosures, NQ, NF, or QO load centers.
Is there a unit-mount equivalent for the JGA36200?
Yes. If your application requires mechanical lugs on both the line and load sides rather than the I-Line plug-on connection, the direct unit-mount equivalent is the Square D JGL36200.
What does the "G" indicate in the JGA36200 catalog number?
The "G" designates the interrupting rating tier within the Square D PowerPacT J-Frame family. For this breaker, the G-rating provides 65kA at 240V, 35kA at 480V, and 18kA at 600V. The "A" following it indicates the I-Line plug-on connection style.
How is the JGA36200 installed into the panel?
This breaker features a plug-on line side connection that pushes directly onto the bus stack of an I-Line panelboard. The load side utilizes standard mechanical lugs to terminate your conductors, accepting 3/0 AWG to 350 kcmil copper or aluminum wire.
What are the magnetic trip adjustment settings for this 200A breaker?
The JGA36200 utilizes a thermal-magnetic trip unit with a fixed thermal element and an adjustable magnetic element. The magnetic trip range can be adjusted between a 1000A hold setting and a 2000A trip setting to customize short-circuit protection.
