Square D JJA36250 Molded Case Circuit Breaker
- 250A
- 3 Pole
- I-Line
Square D
JJA36250
Molded Case Circuit Breaker
Brand
Square D
SKU
JJA36250
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D JJA36250 - 250A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Square D JJA36250 - 250A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | JJA36250 |
| Series | JJA |
| Amperage | 250A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 20kA @ 250VDC |
| Frame Type | JJA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Square D I-Line Switchboards |
| Wire Gauge | 3/0 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Rotary Handle, Lug Kits, Phase Barriers |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, HACR, IEC, NEMA, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Current Limiting, Visual Trip Indicator, Non-Interchangeable Trip, Mercury Free, PVC Free |
Quantity
Square D JJA36250 - 250A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | JJA36250-R |
| Series | JJA |
| Amperage | 250A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 20kA @ 250VDC |
| Frame Type | JJA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Square D I-Line Switchboards |
| Wire Gauge | 3/0 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Rotary Handle, Lug Kits, Phase Barriers |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, HACR, IEC, NEMA, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Current Limiting, Visual Trip Indicator, Non-Interchangeable Trip, Mercury Free, PVC Free |
Similar Items
225A 3 Pole Molded Case Circuit Breaker
200A 3 Pole Molded Case Circuit Breaker
200A 3 Pole Molded Case Circuit Breaker
Description
Engineered for commercial and industrial applications, the Square D JJA36250 is a robust 3-pole molded case circuit breaker from the PowerPacT J-Frame family. It delivers reliable overcurrent protection with a thermal-magnetic trip unit featuring long-time and instantaneous (LI) functions. Designed for seamless integration, this unit installs into Square D I-Line panelboards and switchboards. It serves as an upgrade or replacement for legacy KC36250 and KH36250 breakers.Specifications
| Brand | Square D |
|---|---|
| Part Number | JJA36250 |
| Series | JJA |
| Amperage | 250A |
| Poles | 3 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 20kA @ 250VDC |
| Frame Type | JJA |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Square D I-Line Switchboards |
| Wire Gauge | 3/0 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Rotary Handle, Lug Kits, Phase Barriers |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, HACR, IEC, NEMA, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Current Limiting, Visual Trip Indicator, Non-Interchangeable Trip, Mercury Free, PVC Free |
Product FAQs
8 answersWhich panelboards are compatible with the JJA36250 circuit breaker?
The JJA36250 is designed for Square D I-Line panelboards and switchboards. It uses a plug-on I-Line connection on the line side that attaches directly to the busbar stack, eliminating the need for separate mounting hardware or cables on the supply side.
Does the JJA36250 have an adjustable trip setting?
The thermal overload trip is fixed at 250 amps, but it features an adjustable magnetic instantaneous trip. You can adjust the short-circuit pickup range between 1250 amps and 2500 amps using the dial on the front of the breaker.
What is the difference between the JJA36250, JGA36250, and JDA36250?
All three are 250-amp, 3-pole, I-Line J-Frame breakers, but their short-circuit interrupting ratings differ. The JJA has the highest interrupting capacity at 100kA at 240V and 65kA at 480V. The JGA (65kA at 240V, 35kA at 480V) and JDA (25kA at 240V, 18kA at 480V) have lower ratings. You can substitute a JJA for a JDA or JGA, but you cannot use a lower-rated breaker if the system requires a high interrupting capacity.
How is the JJA36250 wired on the line and load sides?
The line side does not use conventional lugs. It relies entirely on the plug-on I-Line jaw connection to interface directly with the panel bus. The load side is equipped with mechanical lugs that accept 3/0 AWG to 350 kcmil aluminum or copper wire.
Is the JJA36250 rated for 100 percent continuous current?
No, this is a standard-rated circuit breaker, meaning it is rated for 80 percent continuous duty. Under continuous loads lasting three hours or more, the maximum continuous load should not exceed 200 amps.
Can the JJA36250 be used for DC overcurrent protection?
Yes. Because it utilizes a thermal-magnetic trip unit instead of an electronic one, it can be applied in DC systems. It is rated for up to 250VDC with a 20kA interrupting capacity.
What does the ABC phase configuration indicate for this breaker?
The ABC designation specifies the standard phase connections for the I-Line plug-on jaws. When pushed into the panelboard, the jaws engage the A, B, and C busbars in a standard 3-phase sequence.
How can I manually test the mechanical tripping action on the JJA36250?
The breaker includes an integral push-to-trip button on the front cover. Pressing this button mechanically trips the breaker, allowing you to verify that the internal mechanism is operating freely and to confirm the handle moves to the center tripped position before placing it in service.
