Square D KA26225 Molded Case Circuit Breaker
- 225A
- 2 Pole
- I-Line
Square D
KA26225
Molded Case Circuit Breaker
Brand
Square D
SKU
KA26225
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D KA26225 - 225A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
250A 2 Pole Molded Case Circuit Breaker
175A 2 Pole Molded Case Circuit Breaker
150A 2 Pole Molded Case Circuit Breaker
Description
Serving as a direct replacement for aging K-frame installations, the KA26225 is a 2-pole, 225A molded case circuit breaker. It provides reliable thermal-magnetic protection with fixed long-time and adjustable instantaneous trip functions for commercial power distribution. This breaker utilizes Square D's I-Line plug-on mounting system, allowing it to install into compatible I-Line panelboards. Rated to interrupt 25kA at 480VAC, it features standard load-side lugs and a Visi-Trip indicator.Specifications
| Brand | Square D |
|---|---|
| Part Number | KA26225 |
| Series | KA |
| Amperage | 225A |
| Poles | 2 |
| Mounting Style | I-Line |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 42kA @ 240VAC, 25kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | K |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards and Switchboards |
| Wire Gauge | 4 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Product FAQs
7 answersWhat equipment is compatible with the KA26225 circuit breaker?
This breaker is designed specifically for Square D I-Line panelboards and switchboards. Because it utilizes a specialized plug-on bus connection, it cannot be used in standard load centers or unit-mount applications.
Is the Square D KA26225 a current production model?
No, the KA26225 is a legacy K-frame circuit breaker. It is primarily sourced to maintain and service existing infrastructure in older commercial distribution systems rather than for new construction.
What is the modern replacement for the legacy KA26225?
The KA26225 is officially replaced by the Square D PowerPact J-frame series. For a direct 225A, 2-pole I-Line replacement with equivalent interrupting ratings, the JGA262252 is the standard upgrade path.
What do the AB or AC suffixes indicate on KA26225 catalog numbers?
Suffixes such as AB or AC specify the phase connection configuration for the I-Line plug-on mounting. A KA26225AB connects to phases A and B, while a KA26225AC connects to phases A and C on the panelboard bus.
How is the KA26225 secured inside the panelboard?
The breaker utilizes Square D I-Line plug-on phase jaws that press directly onto the panelboard bus stack. It is then mechanically secured to the panel using a built-in mounting bracket, eliminating the need to bolt cables or busbars directly to the line side.
What does the LI trip function code mean for the KA26225?
The LI designation indicates that the thermal magnetic trip unit provides fixed Long-Time protection for thermal overloads and adjustable Instantaneous protection for short circuits.
Why does the KA26225 feature an adjustable magnetic trip?
The adjustable magnetic trip allows an installer to tune the instantaneous short-circuit response threshold. This flexibility is required for proper selective coordination with downstream breakers and other protective devices in the distribution system.
