Square D KAL36070 Molded Case Circuit Breaker
- 70A
- 3 Pole
- Unit Mount
Square D
KAL36070
Molded Case Circuit Breaker
Brand
Square D
SKU
KAL36070
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D KAL36070 - 70A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Square D KAL36070 - 70A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | KAL36070 |
| Series | KAL |
| Amperage | 70A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 42kA @ 240VAC, 25kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | KAL |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D Enclosures, Switchboards, Motor Control Centers |
| Wire Gauge | 4 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Lugs (AL250KA) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Trip-Free Mechanism, Common Trip |
Quantity
Square D KAL36070 - 70A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | KAL36070-R |
| Series | KAL |
| Amperage | 70A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 42kA @ 240VAC, 25kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | KAL |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D Enclosures, Switchboards, Motor Control Centers |
| Wire Gauge | 4 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Lugs (AL250KA) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Trip-Free Mechanism, Common Trip |
Similar Items
90A 3 Pole Molded Case Circuit Breaker
125A 3 Pole Molded Case Circuit Breaker
125A 3 Pole Molded Case Circuit Breaker
Description
Built for commercial power systems, the KAL36070 is a 3-pole, 70A molded case circuit breaker. It provides essential long-time and instantaneous (LI) protection for demanding networks. The unit-mount design allows installation into Square D switchboards and motor control centers. For modern replacements, this legacy K-Frame transitions to the PowerPacT H-Frame (HGL36070). It delivers a 25 kAIC rating at 480VAC and includes an adjustable magnetic trip for precise coordination.Specifications
| Brand | Square D |
|---|---|
| Part Number | KAL36070 |
| Series | KAL |
| Amperage | 70A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 42kA @ 240VAC, 25kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | KAL |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D Enclosures, Switchboards, Motor Control Centers |
| Wire Gauge | 4 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Lugs (AL250KA) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Trip-Free Mechanism, Common Trip |
Product FAQs
7 answersWhat is the modern replacement for the legacy Square D KAL36070?
The KAL36070 is part of the legacy Square D K-Frame family. For modern upgrades, it is typically replaced by a 70A Square D PowerPacT H-Frame unit-mount breaker. Note that retrofitting a PowerPacT breaker into an older enclosure may require a different mounting pan or hardware adaptations.
Which replacement lug kit is compatible with this K-Frame breaker?
The Square D AL250KA mechanical lug kit is the direct replacement for KAL, KHL, KCL, and KIL frame circuit breakers. It includes three lugs rated for 4 AWG to 350 kcmil wire.
What wire sizes are compatible with the standard lugs on the KAL36070?
The standard line and load lugs on this breaker accept 4 AWG to 350 kcmil aluminum or copper (Al/Cu) conductors.
How does the LI trip unit function on this breaker?
The "LI" designation means this thermal-magnetic breaker provides Long-Time (L) and Instantaneous (I) protection. The long-time thermal element is fixed for standard overload protection, while the instantaneous magnetic element is adjustable for short-circuit protection.
Is the KAL36070 rated for use in DC electrical systems?
Yes, in addition to its AC ratings, this breaker is rated for DC applications up to 250VDC, delivering a 10kAIC interrupting rating at that voltage.
How does the mounting style of the KAL36070 differ from KA-frame breakers?
The KAL36070 is a unit-mount (feed-thru) breaker designed to be bolted directly to a backpan or enclosure. In contrast, KA-frame breakers feature a plug-on design specifically for Square D I-Line panelboards.
Where is this unit-mount breaker typically installed?
It is designed for installation in compatible Square D enclosures, switchboards, and motor control centers that accommodate legacy unit-mount K-Frame breakers.
