Square D KAL36090 Molded Case Circuit Breaker
- 90A
- 3 Pole
- Unit Mount
Square D
KAL36090
Molded Case Circuit Breaker
Brand
Square D
SKU
KAL36090
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D KAL36090 - 90A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Square D KAL36090 - 90A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | KAL36090 |
| Series | KAL |
| Amperage | 90A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 42kA @ 240VAC, 25kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | KAL |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D Enclosures, Switchboards, Motor Control Centers |
| Wire Gauge | 4 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Quantity
Square D KAL36090 - 90A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | KAL36090 |
| Series | KAL |
| Amperage | 90A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 42kA @ 240VAC, 25kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | KAL |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D Enclosures, Switchboards, Motor Control Centers |
| Wire Gauge | 4 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Similar Items
70A 3 Pole Molded Case Circuit Breaker
125A 3 Pole Molded Case Circuit Breaker
125A 3 Pole Molded Case Circuit Breaker
Description
Operating as a vital safety component, the Square D KAL36090 is a 3-pole, 90A molded case circuit breaker. It features fixed thermal and adjustable magnetic trip elements to provide long-time and instantaneous (LI) protection. This unit mount device is engineered to fit into legacy Square D switchboards. When modernizing electrical panels, this K-Frame breaker is replaced by the PowerPacT H-Frame equivalent (HGL36090). Capable of handling 600VAC, it delivers 25 kAIC at 480V.Specifications
| Brand | Square D |
|---|---|
| Part Number | KAL36090 |
| Series | KAL |
| Amperage | 90A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 42kA @ 240VAC, 25kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | KAL |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D Enclosures, Switchboards, Motor Control Centers |
| Wire Gauge | 4 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Product FAQs
6 answersWhat is the current replacement for the legacy KAL36090?
For panel upgrades or replacements, this legacy K-Frame breaker is superseded by the Square D PowerPacT H-Frame series, specifically catalog number HGL36090.
What type of panels accept the KAL36090?
This breaker is designed for legacy Square D equipment, including switchboards, motor control centers, and individual enclosures configured for unit-mount K-Frame breakers.
Do I need to purchase lugs separately for the KAL36090?
No, this feed-thru breaker comes with factory-installed line and load lugs that accept 4 AWG to 350 kcmil aluminum or copper wire.
How is the KAL36090 mounted and connected?
It utilizes a unit-mount, feed-thru configuration. The breaker bolts directly to the enclosure or backpan and requires hardwired connections at both the line and load lugs.
How does the trip adjustability work on the KAL36090?
The breaker is equipped with a thermal-magnetic trip unit that provides fixed thermal protection for overloads (long-time) and an adjustable magnetic dial to fine-tune the instantaneous short-circuit response.
Can the KAL36090 be used in DC control circuits or battery systems?
Yes, this breaker is rated for up to 250VDC with a 10kA interrupting capacity, making it suitable for various industrial DC applications.
