Square D QDP22200TM Molded Case Circuit Breaker
- 200A
- 2 Pole
- Bolt-On
Square D
QDP22200TM
Molded Case Circuit Breaker
Brand
Square D
SKU
QDP22200TM
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D QDP22200TM - 200A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Square D QDP22200TM - 200A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | QDP22200TM |
| Series | QDP |
| Amperage | 200A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 208Y/120VAC, 240VAC |
| Phase | 1 |
| AIC Rating | 25kA @ 208Y/120VAC, 25kA @ 240VAC |
| Frame Type | QDP |
|---|---|
| Terminal Type | Stud/Tapped Pad |
| For Use With | EZ Meter-Pak Metering Centers, MP Meter-Pak Metering Centers |
| Wire Gauge | 4 AWG - 300 kcmil (Al/Cu) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release, Padlock Attachment |
|---|---|
| Accessories | Terminal Nut Kit (Line Side) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Sold out
Quantity
Square D QDP22200TM - 200A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | QDP22200TM |
| Series | QDP |
| Amperage | 200A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 208Y/120VAC, 240VAC |
| Phase | 1 |
| AIC Rating | 25kA @ 208Y/120VAC, 25kA @ 240VAC |
| Frame Type | QDP |
|---|---|
| Terminal Type | Stud/Tapped Pad |
| For Use With | EZ Meter-Pak Metering Centers, MP Meter-Pak Metering Centers |
| Wire Gauge | 4 AWG - 300 kcmil (Al/Cu) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release, Padlock Attachment |
|---|---|
| Accessories | Terminal Nut Kit (Line Side) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Similar Items
175A 2 Pole Molded Case Circuit Breaker
125A 2 Pole Molded Case Circuit Breaker
110A 2 Pole Molded Case Circuit Breaker
Description
Engineered for heavy-duty metering setups, the QDP22200TM is a 200-amp, two-pole PowerPacT Q-Frame circuit breaker. It provides fixed thermal and magnetic trip functions alongside a Visi-Trip indicator for rapid diagnostics. The unit-mount configuration bolts into EZ Meter-Pak and MP Meter-Pak centers. It is fully backwards compatible, serving as a substitute for discontinued Q22200 breakers.Specifications
| Brand | Square D |
|---|---|
| Part Number | QDP22200TM |
| Series | QDP |
| Amperage | 200A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 208Y/120VAC, 240VAC |
| Phase | 1 |
| AIC Rating | 25kA @ 208Y/120VAC, 25kA @ 240VAC |
| Frame Type | QDP |
|---|---|
| Terminal Type | Stud/Tapped Pad |
| For Use With | EZ Meter-Pak Metering Centers, MP Meter-Pak Metering Centers |
| Wire Gauge | 4 AWG - 300 kcmil (Al/Cu) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release, Padlock Attachment |
|---|---|
| Accessories | Terminal Nut Kit (Line Side) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Product FAQs
6 answersWhat metering centers are compatible with the QDP22200TM circuit breaker?
This breaker is designed for installation in Square D EZ Meter-Pak and MP Meter-Pak Metering Centers.
What type of terminal connections does the QDP22200TM feature?
Based on the catalog nomenclature, this breaker features studs with nuts and washers on the line side and mechanical box lugs on the load side.
What wire sizes are accepted by the load side lugs on this breaker?
The mechanical lugs on the load side are rated to accept either aluminum or copper conductors ranging from 4 AWG to 300 kcmil.
Can the QDP22200TM be used to replace older Square D breakers?
Yes, the PowerPacT Q-frame series serves as a direct replacement for discontinued Square D Q2 Series devices, including the Q22200.
What does the D in the QDP22200TM catalog number indicate?
The D designates the interrupting rating tier within the PowerPacT Q-Frame family, specifying a 25kA short circuit current rating at 240VAC.
Are the trip settings adjustable on the QDP22200TM?
No, this breaker features a thermal magnetic trip unit with fixed long-time and fixed instantaneous trip functions.
