Square D QO115AFI AFCI Miniature Circuit Breaker
- 15A
- 1 Pole
- Plug-On
Square D
QO115AFI
AFCI Miniature Circuit Breaker
Brand
Square D
SKU
QO115AFI
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D QO115AFI - 15A AFCI Miniature Circuit Breaker
New
Quantity
Quantity
Square D QO115AFI - 15A AFCI Miniature Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | QO115AFI |
| Series | QO |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC |
| Frame Type | QO |
|---|---|
| Terminal Type | Pressure Plate |
| For Use With | QO Load Centers, NQ Panelboards, NQOD Panelboards |
| Wire Gauge | 14-8 AWG (Cu), 12-8 AWG (Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Special Classification | AFCI |
|---|---|
| Available Options | Padlock Attachment |
| Accessories | Pigtail Neutral |
| Standards | CSA C22.2 No. 5, UL 489, UL 1699, HACR |
| Approval | CSA, UL |
| Temp Rating | 40C |
Sold out
Quantity
Square D QO115AFI - 15A AFCI Miniature Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Part Number | QO115AFI-R |
| Series | QO |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC |
| Frame Type | QO |
|---|---|
| Terminal Type | Pressure Plate |
| For Use With | QO Load Centers, NQ Panelboards, NQOD Panelboards |
| Wire Gauge | 14-8 AWG (Cu), 12-8 AWG (Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Special Classification | AFCI |
|---|---|
| Available Options | Padlock Attachment |
| Accessories | Pigtail Neutral |
| Standards | CSA C22.2 No. 5, UL 489, UL 1699, HACR |
| Approval | CSA, UL |
| Temp Rating | 40C |
Similar Items
20A AFCI Miniature Circuit Breaker
20A AFCI Miniature Circuit Breaker
20A AFCI Miniature Circuit Breaker
Description
Built for residential applications, the Square D QO115AFI delivers branch and feeder arc-fault protection for 120V circuits. This 15-amp, single-pole breaker features a pigtail neutral and the exclusive Visi-Trip indicator for quick fault identification. It installs into QO load centers, NQ, and NQOD panelboards. Note that this legacy model is replaced by the QO115CAFI combination AFCI to meet modern NEC codes. Rated at 10kAIC, it defends against overloads, short circuits, and parallel arcs.Specifications
| Brand | Square D |
|---|---|
| Part Number | QO115AFI |
| Series | QO |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC |
| Frame Type | QO |
|---|---|
| Terminal Type | Pressure Plate |
| For Use With | QO Load Centers, NQ Panelboards, NQOD Panelboards |
| Wire Gauge | 14-8 AWG (Cu), 12-8 AWG (Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Special Classification | AFCI |
|---|---|
| Available Options | Padlock Attachment |
| Accessories | Pigtail Neutral |
| Standards | CSA C22.2 No. 5, UL 489, UL 1699, HACR |
| Approval | CSA, UL |
| Temp Rating | 40C |
Product FAQs
6 answersWhat panels accept the QO115AFI circuit breaker?
This plug-on breaker is compatible with Square D QO load centers, NQ panelboards, and NQOD panelboards. It will not fit Homeline or other manufacturer panels.
Does the QO115AFI require a connection to the neutral bar?
Yes, this breaker is equipped with a pigtail neutral wire. The pigtail must be routed and secured to the neutral bus bar in the panel for the arc-fault circuitry to operate correctly.
What is the modern replacement for the QO115AFI?
The QO115AFI is a legacy branch and feeder AFCI. It has been replaced by the QO115CAFI, which is a combination AFCI designed to meet current NEC requirements by detecting both parallel and series arcing faults.
How does the Visi-Trip indicator work on this breaker?
When the breaker trips due to an overload, short circuit, or arc fault, the handle moves to the center position and a bright red indicator appears in the window. This allows for rapid identification of the tripped circuit.
What wire gauges are supported by the QO115AFI terminals?
The pressure plate terminals are rated for 14 to 8 AWG copper wire, or 12 to 8 AWG aluminum wire.
Can the QO115AFI be installed in a Plug-On Neutral load center?
Yes, it can be installed in a Plug-On Neutral panel, but you must still manually connect the attached pigtail wire to the neutral bar. For a pigtail-free installation in those specific panels, the QO115PCAFI is required.
