Square D QOB350GFI GFCI Miniature Circuit Breaker
- 50A
- 3 Pole
- Bolt-On
Square D
QOB350GFI
GFCI Miniature Circuit Breaker
Brand
Square D
SKU
QOB350GFI
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D QOB350GFI - 50A GFCI Miniature Circuit Breaker
New
Quantity
Quantity
Square D QOB350GFI - 50A GFCI Miniature Circuit Breaker
New
Quantity
| Brand | Square D |
|---|---|
| Part Number | QOB350GFI |
| Series | QOB |
| Amperage | 50A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 208Y/120VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 208Y/120VAC |
| Frame Type | QOB |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | NQ Panelboards, NQOD Panelboards |
| Wire Gauge | 12-4 AWG (Al), 14-6 AWG (Cu) |
| Max Wire | 4 AWG (Al), 6 AWG (Cu) |
| Min Wire | 12 AWG (Al), 14 AWG (Cu) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | GFCI |
|---|---|
| Available Options | Auxiliary Switch, Alarm Switch, Handle Padlock Attachment |
| Accessories | Pigtail Neutral, Load Side Lugs Included |
| Standards | CSA C22.2 No. 144, UL 489, UL 943 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Sold out
Quantity
Square D QOB350GFI - 50A GFCI Miniature Circuit Breaker
Re-Certified
Quantity
| Brand | Square D |
|---|---|
| Series | QOB |
| Amperage | 50A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 208Y/120VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 208Y/120VAC |
| Frame Type | QOB |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | NQ Panelboards, NQOD Panelboards |
| Wire Gauge | 12-4 AWG (Al), 14-6 AWG (Cu) |
| Max Wire | 4 AWG (Al), 6 AWG (Cu) |
| Min Wire | 12 AWG (Al), 14 AWG (Cu) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | GFCI |
|---|---|
| Available Options | Auxiliary Switch, Alarm Switch, Handle Padlock Attachment |
| Accessories | Pigtail Neutral, Load Side Lugs Included |
| Standards | CSA C22.2 No. 144, UL 489, UL 943 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Similar Items
30A GFCI Miniature Circuit Breaker
20A GFCI Miniature Circuit Breaker
15A GFCI Miniature Circuit Breaker
Description
Engineered for commercial applications, the Square D QOB350GFI delivers 50A overcurrent and Class A ground-fault protection. This three-pole breaker features a 6mA trip threshold to safeguard personnel from electrical hazards. Designed for bolt-on installation, it mounts securely into Square D NQ and NQOD panelboards. The unit includes a pigtail neutral connection. Rated for 10kAIC at 208Y/120VAC, it utilizes the Visi-Trip indicator to easily identify tripped circuits.Specifications
| Brand | Square D |
|---|---|
| Part Number | QOB350GFI |
| Series | QOB |
| Amperage | 50A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 208Y/120VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 208Y/120VAC |
| Frame Type | QOB |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | NQ Panelboards, NQOD Panelboards |
| Wire Gauge | 12-4 AWG (Al), 14-6 AWG (Cu) |
| Max Wire | 4 AWG (Al), 6 AWG (Cu) |
| Min Wire | 12 AWG (Al), 14 AWG (Cu) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | GFCI |
|---|---|
| Available Options | Auxiliary Switch, Alarm Switch, Handle Padlock Attachment |
| Accessories | Pigtail Neutral, Load Side Lugs Included |
| Standards | CSA C22.2 No. 144, UL 489, UL 943 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Product FAQs
6 answersCan I install this 3-pole GFCI breaker on a 3-phase load that does not use a neutral?
Yes [1.3.1]. The breaker can protect a 3-wire load without a load neutral connection. However, the white neutral pigtail on the breaker must still be connected to the panel neutral bar to power the internal ground fault circuitry.
Will the QOB350GFI fit in a standard QO residential load center?
No. This is a QOB bolt-on circuit breaker designed for commercial NQ and NQOD panelboards. Standard residential QO load centers require plug-on circuit breakers like the QO350GFI.
How many panel spaces does this breaker require?
As a 3-pole circuit breaker, it requires three standard spaces in your panelboard.
What level of ground fault protection does this circuit breaker provide?
It provides Class A ground fault protection for personnel, which means it will trip when it detects a ground fault current of approximately 4 to 6 milliamps (mA).
What is the plug-on equivalent for this bolt-on breaker?
If your electrical panel requires plug-on connections instead of bolt-on, the correct catalog number to order is QO350GFI.
Can I use this breaker for Equipment Protection (EPD) applications?
No. This model provides Class A personnel protection. If your application requires a 30mA equipment protection level, you must use a breaker with an EPD suffix instead of GFI.
