ABB / General Electric THQP125 Miniature Circuit Breaker
- 25A
- 1 Pole
- Plug-On
ABB / General Electric
THQP125
Miniature Circuit Breaker
Brand
ABB / General Electric
SKU
THQP125
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric THQP125 - 25A 1 Pole Miniature Circuit Breaker
New
Quantity
Similar Items
20A 1 Pole Miniature Circuit Breaker
35A 1 Pole Miniature Circuit Breaker
15A 1 Pole Miniature Circuit Breaker
Description
Offering a specialized 25-amp rating, this single-pole miniature breaker is ideal for specific residential or light commercial applications requiring precise overcurrent protection. The half-inch slim profile mounts effortlessly into GE PowerMark Gold and Q-Line load centers, helping facility managers optimize enclosure capacity. Built with a trip-free mechanism, it ensures the circuit opens safely under fault conditions even if the handle is held in the ON position.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | THQP125 |
| Series | THQP |
| Amperage | 25A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | THQP |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | GE Q-Line Load Centers, PowerMark Gold Load Centers |
| Wire Gauge | 14-8 AWG (Cu), 12-8 AWG (Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment |
|---|---|
| Standards | CSA C22.2 No. 5, HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Quick-Make/Quick-Break, Trip-Free Mechanism, Reverse Feed |
Product FAQs
6 answersWhat is the difference between GE THQP and THQL breakers?
THQP breakers are half-size, measuring 1/2 inch wide per pole, allowing two circuits to fit in a single standard slot. THQL breakers are full-size, measuring 1 inch wide per pole. THQP breakers only fit in panel slots specifically designed to accept them.
Can I install a THQP125 in any GE load center?
No. While THQP breakers are designed for GE Q-Line and PowerMark Gold load centers, they require specific slots that accept half-inch breakers. Check the panelboard label or wiring diagram to confirm which positions allow THQP installation.
How does the THQP125 connect to the panel busbar?
The THQP125 uses a plug-in connection designed specifically for GE load centers that support half-inch breakers. It attaches to the busbar using a specialized clip system that differs from standard 1-inch breakers, ensuring it can only be installed in approved tandem slots.
Is the THQP125 HACR rated?
Yes, this breaker is HACR rated, making it suitable for use with heating, air conditioning, and refrigeration equipment that requires this specific listing.
Can I use a THQP breaker to replace a standard THQL breaker?
Not directly. Standard THQL breakers are 1-inch wide, while THQP breakers are 1/2-inch wide. They occupy different amounts of space and attach to the busbar differently. You must verify your panel accepts half-inch breakers before substituting.
What does the LI trip function code mean on this breaker?
The LI designation indicates a thermal-magnetic trip mechanism. The L stands for Long-Time, which provides thermal protection against sustained overloads. The I stands for Instantaneous, which uses a magnetic element to trip immediately during a short circuit.
