ABB / General Electric TMQD22175 Molded Case Circuit Breaker
- 175A
- 2 Pole
- Bolt-On
ABB / General Electric
TMQD22175
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
TMQD22175
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric TMQD22175 - 175A 2 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
ABB / General ElectricTMQD22125
125A 2 Pole Molded Case Circuit Breaker
ABB / General ElectricTMQD22100
100A 2 Pole Molded Case Circuit Breaker
ABB / General ElectricTMQD22070
70A 2 Pole Molded Case Circuit Breaker
Description
Part of the GE MeterMod family, this 175A commercial molded case circuit breaker delivers reliable thermal-magnetic protection. It is engineered for heavy-duty residential and commercial power distribution applications. This bolt-on MCCB mounts into GE Meter Mod III meter stacks and A-Series panelboards. It is superseded by the TMQV22175 in newer installations. Rated for 100kAIC at 120/240VAC, the breaker features a non-interchangeable trip unit and is HACR rated for HVAC equipment.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TMQD22175 |
| Series | TMQD |
| Amperage | 175A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 100kA @ 120/240VAC |
| Frame Type | TMQD |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Meter Mod III Meter Stacks, GE A-Series Panelboards |
| Wire Gauge | 1 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | 1 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Lug Kits, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs |
| Standards | HACR, UL 489 |
| Approval | UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Extra High Interrupting Capacity, Non-Interchangeable Trip, Common Trip, Reverse Feed |
Product FAQs
4 answersWhere is the TMQD22175 typically installed?
This bolt-on breaker is designed for GE Meter Mod III modular metering stacks and GE A-Series panelboards. It is frequently utilized as a tenant main disconnect in 200A or 225A meter sockets.
What is the modern replacement for the TMQD22175?
The TMQD22175 has been superseded by the TMQV22175 frame. The TMQV series maintains the same physical footprint, 175A rating, and 100kAIC capacity for GE Meter Mod and A-Series panelboards.
Is the TMQD22175 interchangeable with TQD or THQD breakers?
Yes. The TMQD22175 shares the same physical dimensions and bolt-on mounting configuration as the TQD22175 (10kAIC) and THQD22175 (22kAIC). It can be used to upgrade these breakers in systems requiring a 100kAIC fault current rating.
Can the TMQD22175 be used for HVAC applications?
Yes. The TMQD22175 is HACR rated, meaning it is approved for use with heating, air conditioning, and refrigeration equipment loads.
