Siemens 3VA41204ED140AA0 3VA4120-4ED14-0AA0 - 20A 1 Pole Molded Case Circuit Breaker
- 20A
- 1 Pole
- Panel Mount
Siemens
3VA41204ED140AA0
3VA4120-4ED14-0AA0 - 20A 1 Pole Molded Case Circuit Breaker
Brand
Siemens
SKU
3VA41204ED140AA0
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens 3VA4120-4ED14-0AA0 - 20A 1 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Quantity
Siemens 3VA4120-4ED14-0AA0 - 20A 1 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Series | 3VA4 |
| Amperage | 20A |
| Poles | 1 |
| Mounting Style | Panel Mount |
| Voltage | 120VAC, 277VAC, 125VDC, 347VAC |
| Phase | 1 |
| AIC Rating | 65kA @ 120VAC, 25kA @ 277VAC, 14kA @ 125VDC, 14kA @ 347VAC |
| Frame Type | 3VA41 |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3, P4, P5 Panelboards, Switchboards |
| Wire Gauge | 14 AWG - 8 AWG (Cu/Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CE, CSA, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Reverse Feed, SWD Rated, HID Rated |
Sold out
Quantity
Siemens 3VA4120-4ED14-0AA0 - 20A 1 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Series | 3VA4 |
| Amperage | 20A |
| Poles | 1 |
| Mounting Style | Panel Mount |
| Voltage | 120VAC, 277VAC, 125VDC, 347VAC |
| Phase | 1 |
| AIC Rating | 65kA @ 120VAC, 25kA @ 277VAC, 14kA @ 125VDC, 14kA @ 347VAC |
| Frame Type | 3VA41 |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3, P4, P5 Panelboards, Switchboards |
| Wire Gauge | 14 AWG - 8 AWG (Cu/Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CE, CSA, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Reverse Feed, SWD Rated, HID Rated |
Similar Items
25A 1 Pole Molded Case Circuit Breaker
30A 1 Pole Molded Case Circuit Breaker
35A 1 Pole Molded Case Circuit Breaker
Description
Designed for versatile power distribution, the Siemens 3VA4120-4ED14-0AA0 is a 20A, 1-pole molded case circuit breaker. This unit fits into Siemens P1 through P5 panelboards and compatible switchboards. It provides an excellent replacement option for legacy ED61B020, ED41B020, and ED21B020 breakers. Equipped with a thermal-magnetic trip unit, it delivers LI protection with a 25kAIC rating at 277VAC. The breaker is HACR, HID, and SWD rated, accommodating reverse feed applications.Specifications
| Brand | Siemens |
|---|---|
| Series | 3VA4 |
| Amperage | 20A |
| Poles | 1 |
| Mounting Style | Panel Mount |
| Voltage | 120VAC, 277VAC, 125VDC, 347VAC |
| Phase | 1 |
| AIC Rating | 65kA @ 120VAC, 25kA @ 277VAC, 14kA @ 125VDC, 14kA @ 347VAC |
| Frame Type | 3VA41 |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3, P4, P5 Panelboards, Switchboards |
| Wire Gauge | 14 AWG - 8 AWG (Cu/Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CE, CSA, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Reverse Feed, SWD Rated, HID Rated |
Product FAQs
6 answersWhat mounting hardware is required to install this breaker in P1 to P5 panelboards?
While the 3VA4120-4ED14-0AA0 integrates into Siemens P1 through P5 panelboards, you must use the specific 3VA41 branch breaker mounting strap kit designed for your panelboard generation. It will not mount to legacy ED-frame connection straps.
Can I use the 3VA4120-4ED14-0AA0 to replace an older ED41B020 breaker?
Yes. This 3VA41 frame breaker serves as a modern functional replacement for legacy Siemens 1-pole ED-frame breakers, including the ED41B020, ED61B020, and ED21B020. Upgrading an existing panelboard from ED-frame to 3VA4-frame breakers will require replacing the original connection strap kit.
Does the 3VA4120-4ED14-0AA0 support reverse feed wiring?
Yes. This unit is certified for reverse feed applications. The internal thermal-magnetic trip unit will protect the circuit reliably regardless of whether the line power is landed on the top or bottom terminals.
Is this breaker approved for continuous switching of lighting loads?
Yes. Because it carries SWD (Switching Duty) and HID (High-Intensity Discharge) ratings, it can be safely used to manually switch 120V or 277V fluorescent or HID lighting circuits on and off on a regular basis without degrading the contacts.
Are the trip limits on the TM210 trip unit adjustable?
No. The TM210 thermal-magnetic trip unit installed in this breaker features a fixed long-time overload setting and a fixed instantaneous short-circuit setting. It cannot be field-adjusted to different amperage thresholds.
Can I use this breaker to protect dedicated HVAC equipment?
Yes. The breaker holds an HACR rating, making it suitable for overcurrent protection in heating, air conditioning, and refrigeration equipment in accordance with NEC guidelines.
