Eaton / Cutler-Hammer PDG13M0045TFFJ Molded Case Circuit Breaker
- 45A
- 3 Pole
- Panel Mount
Eaton / Cutler-Hammer
PDG13M0045TFFJ
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
PDG13M0045TFFJ
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer PDG13M0045TFFJ - 45A 3 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
Eaton / Cutler-HammerPDG13M0040TFFJ
40A 3 Pole Molded Case Circuit Breaker
Eaton / Cutler-HammerPDG13M0060TFFJ
60A 3 Pole Molded Case Circuit Breaker
Eaton / Cutler-HammerPDG13M0030TFFJ
30A 3 Pole Molded Case Circuit Breaker
Description
A drop-in replacement for legacy EGH3045FFG units, the Eaton PDG13M0045TFFJ is a 3-pole, 45A molded case circuit breaker. It belongs to the globally rated Power Defense family, offering fixed thermal and magnetic trip functions. Designed for commercial and industrial applications, this Frame 1 MCCB installs into Eaton Pow-R-Line and Power Defense panelboards. It includes standard line and load terminals. This current-limiting breaker boasts a robust 65kAIC interrupting rating at 480VAC.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Series | PDG1 |
| Amperage | 45A |
| Poles | 3 |
| Mounting Style | Panel Mount |
| Voltage | 240VAC, 480VAC, 600Y/347VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600Y/347VAC, 42kA @ 250VDC |
| Frame Type | Complete Breaker |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | Eaton Power Defense Panelboards, Eaton Pow-R-Line Panelboards |
| Wire Gauge | 14 AWG - 3/0 AWG (Al/Cu) |
| Max Wire | 3/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, DIN Rail Adapter, Rotary Handle |
|---|---|
| Accessories | Standard Line and Load Terminals (PDG1X3T125) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489, RoHS Compliant |
| Approval | CCC, CE, CSA, IEC, RoHS, UL |
| Temp Rating | -20C to 70C |
| Construction Features | Current Limiting, Globally Rated, RoHS Compliant, HACR Rated |
Product FAQs
6 answersWhat do the "M" and "TFFJ" designations mean in the PDG13M0045TFFJ part number?
The "M" indicates the breaker's interrupting rating tier, providing 65kAIC at 480VAC. The "TFF" suffix specifies a thermal-magnetic trip unit with fixed thermal and fixed magnetic settings. The "J" confirms that standard line and load box lugs are included.
Does this breaker have adjustable trip settings?
No, the PDG13M0045TFFJ features a fixed thermal-magnetic trip unit. Both the long-time (overload) and instantaneous (short-circuit) trip settings are factory-fixed and cannot be adjusted in the field.
How is the 250VDC rating achieved on this 3-pole breaker?
For DC applications, the 250VDC rating is achieved by wiring two of the breaker's poles in series. This is a standard configuration requirement for Eaton Power Defense thermal-magnetic breakers used in DC circuits.
Can I use this to replace an older Cutler-Hammer EG-frame breaker?
Yes, the Eaton Power Defense Frame 1 (PDG1) series is the direct modern replacement for legacy Cutler-Hammer Series G EG-frame molded case circuit breakers.
What panelboards are designed to accept this Power Defense breaker?
The PDG13M0045TFFJ is engineered for installation in Eaton Power Defense panelboards, as well as Eaton Pow-R-Line and Pow-R-Line Xpert switchboards and panelboards.
What does the "G" in the PDG1 series prefix stand for?
The "G" indicates that the breaker is globally rated. It is certified to meet multiple international standards, including UL, CSA, and IEC, making it suitable for worldwide application.
