Federal Pacific NE114060 Molded Case Circuit Breaker
- 60A
- 1 Pole
- Bolt-On
Federal Pacific
NE114060
Molded Case Circuit Breaker
Brand
Federal Pacific
SKU
NE114060
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Federal Pacific NE114060 - 60A 1 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
20A 1 Pole Molded Case Circuit Breaker
15A 1 Pole Molded Case Circuit Breaker
15A 1 Pole Molded Case Circuit Breaker
Description
Providing a seamless hardware match for aging infrastructure, this 60-amp single-pole breaker integrates into Federal Pacific NE and NBLP panelboards. The bolt-on configuration ensures a secure mechanical connection, replacing original NE114060 or NB111060 components seamlessly. Tested for vibration resistance and carrying an HACR rating, it handles commercial HVAC loads while maintaining a 14kA interrupt capacity at 120VAC for reliable circuit defense.Specifications
| Brand | Federal Pacific |
|---|---|
| Series | NE |
| Amperage | 60A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 125VDC |
| Phase | 1 |
| AIC Rating | 14kA @ 120VAC, 10kA @ 125VDC |
| Frame Type | NE |
|---|---|
| Terminal Type | Lugs |
| For Use With | Federal Pacific NE Panelboards, NBLP Panelboards |
| Wire Gauge | 14-2 AWG |
| Max Wire | 2 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Bell Alarm |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2, NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Non-Interchangeable Trip, Reverse Feed, Vibration Tested |
Product FAQs
7 answersWhich panelboards accept the Federal Pacific NE114060 circuit breaker?
This breaker is designed to integrate directly into legacy Federal Pacific NE and NBLP panelboards without requiring aftermarket adapters or modifications.
Can the NE114060 be used to replace other Federal Pacific catalog numbers?
Yes, in addition to replacing original NE114060 units, this breaker serves as a seamless replacement for NB111060 components in compatible enclosures.
Is the NE114060 rated for use with HVAC equipment?
Yes, this breaker carries an HACR rating, meaning it is tested and approved to handle the inrush currents associated with commercial heating, ventilation, and air conditioning motor loads.
What wire gauge range is supported by the terminals on the NE114060?
The integrated load side lugs accommodate conductors ranging from 14 AWG up to 2 AWG.
Does this breaker require a specific mounting kit for installation?
No additional mounting kits are required. It utilizes a standard bolt-on configuration that secures directly to the busbar in Federal Pacific NE and NBLP panels.
What type of protection does the trip unit provide?
The breaker uses a fixed thermal-magnetic mechanism to deliver both long-time delay for overloads and instantaneous trip functions for short-circuit faults.
Can the NE114060 be used in DC power applications?
Yes, alongside its standard AC ratings, this breaker is certified for use in 125VDC circuits with a 10kA interrupting capacity.
