Federal Pacific NE114090 Molded Case Circuit Breaker
- 90A
- 1 Pole
- Bolt-On
Federal Pacific
NE114090
Molded Case Circuit Breaker
Brand
Federal Pacific
SKU
NE114090
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Federal Pacific NE114090 - 90A 1 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
70A 1 Pole Molded Case Circuit Breaker
60A 1 Pole Molded Case Circuit Breaker
20A 1 Pole Molded Case Circuit Breaker
Description
Serving as an exact replacement component, this 90A single-pole breaker maintains safety in existing commercial and industrial electrical systems. The bolt-on configuration fits perfectly into Federal Pacific NE and NBLP panelboards, eliminating the need for complex retrofits. Featuring a non-interchangeable thermal-magnetic trip, it delivers a 14kAIC interrupting rating at 120VAC. This N-frame device includes load side lugs and supports reverse feed applications for installation flexibility.Specifications
| Brand | Federal Pacific |
|---|---|
| Part Number | NE114090 |
| Series | NE |
| Amperage | 90A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC |
| Phase | 1 |
| AIC Rating | 14kA @ 120VAC |
| Frame Type | NE |
|---|---|
| Terminal Type | Lugs |
| For Use With | Federal Pacific NE Panelboards, NBLP Panelboards |
| Wire Gauge | 14-1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Bell Alarm |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Non-Interchangeable Trip |
Product FAQs
6 answersWhich panelboards are compatible with the Federal Pacific NE114090 circuit breaker?
This bolt-on N-Frame breaker is designed for direct installation in legacy Federal Pacific NE and NBLP panelboards.
What wire sizes are accepted by the lugs on the NE114090?
The load side lugs on this breaker accommodate conductors ranging from 14 AWG to 1/0 AWG.
Can the Federal Pacific NE114090 be used in reverse feed applications?
Yes, this non-interchangeable thermal-magnetic breaker supports reverse feed applications, providing additional installation flexibility.
What type of trip unit does the NE114090 utilize?
It features a fixed thermal-magnetic trip unit that provides long-time and instantaneous (LI) overcurrent protection.
Is the Federal Pacific NE114090 a Stab-Lok breaker?
No, the NE114090 is a bolt-on molded case circuit breaker belonging to the N-Frame family. It is used in commercial NE and NBLP panelboards, rather than residential Stab-Lok load centers.
Does this breaker require aftermarket adapters to fit into FPE NE panels?
No, this breaker serves as a direct replacement component that bolts directly into Federal Pacific NE and NBLP panelboards without the need for complex retrofits or adapters.
