ABB / General Electric TEY1100 Miniature Circuit Breaker
- 100A
- 1 Pole
- Bolt-On
ABB / General Electric
TEY1100
Miniature Circuit Breaker
Brand
ABB / General Electric
SKU
TEY1100
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric TEY1100 - 100A 1 Pole Miniature Circuit Breaker
New
Quantity
Similar Items
60A 1 Pole Miniature Circuit Breaker
30A 1 Pole Miniature Circuit Breaker
25A 1 Pole Miniature Circuit Breaker
Description
Engineered for heavy commercial applications, this 100-amp single-pole device provides reliable overcurrent protection. The unit utilizes a proven thermal-magnetic trip mechanism with quick-make and quick-break functionality to minimize arcing. It mounts into standard GE A-Series panelboards using a reliable bolt-on connection. The load-side lugs accept 4 to 1/0 AWG copper or 2 to 1/0 AWG aluminum conductors for flexible wiring. Rated for 65kAIC at 120VAC, it meets rigorous industrial demands.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TEY1100 |
| Series | TEY |
| Amperage | 100A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 240VAC, 277VAC, 125VDC, 120/240VAC |
| Phase | 1 |
| AIC Rating | 65kA @ 120VAC, 14kA @ 240VAC, 14kA @ 277VAC, 10kA @ 125VDC, 14kA @ 120/240VAC |
| Frame Type | UL, CSA |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE A-Series Panelboards |
| Wire Gauge | 4 AWG - 1/0 AWG (Cu), 2 AWG - 1/0 AWG (Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 4 AWG (Cu), 2 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Bell Alarm, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, HID Rated, Non-Interchangeable Trip, Quick-Make/Quick-Break |
Product FAQs
4 answersWhat panelboards are compatible with the TEY1100 circuit breaker?
This breaker is designed for installation in GE A-Series panelboards, specifically AE and AQ lighting and distribution panels. It secures directly to the interior busbar using a bolt-on connection.
What is the recommended mounting torque for installing this breaker?
When securing the breaker to the panelboard busbar, the bolt-on mounting screw should be tightened to 35 lb-in to ensure a proper and safe electrical connection.
Is the TEY1100 suitable for reverse feeding applications?
Yes, standard TEY series breakers do not have line and load markings and are suitable for reverse feeding. Note that higher-rated versions like the TEYF series are marked and cannot be reverse fed.
Are there higher interrupting capacity alternatives to the TEY1100?
Yes. If your electrical system requires a higher fault current rating at 277VAC, you can upgrade to the TEYF1100, which provides an 18kAIC rating. Other high-interrupting options for this form factor include the TEYD, TEYH, and TEYL series.
